POVISON DT046AW14 Installation Instruction

1. Place the base on the hardware feet, align it with the corresponding holes, put in the hexagon socket screws and gasket,
and tighten the screws to 1/2 of the installation length. (Please be careful not to fully tighten the screws)
2. Place the frame on the hardware feet. Since the screws at the bottom has not tightened, you can move the frame
appropriately, and adjust the screw holes on the upper end to make sure they are all aligned, then put in the screws and
gasket, and tighten the screws to the installation 1/2 of the length. After all the screws are inserted, use wrench to tighten
the screws one by one.
Hexagon Socket
Machine Screws
（M8*25mm）
Gasket
Hexagon Socket
Machine Screws
（M8*25mm）
Gasket
Installation instruction
DT046AW14/16/18/20 Installation
The number of people needed for installation ： 2
Please read the manual carefully
①
before installing this product. And
strictly follow the installation process
Please take good care of this manual
②
for your next installation
Note: Before installation, screw all
③
the screws to 1/2 of the length of the
installation. After all screws are half
screwed in, tighten them all
together.
On a red ribbon are furniture
Parts list
installation accessories
Quantity
Serial
required for
Shape Name
number
installation
Hexagon Socket
A Machine Screws 16
（ M8*25mm ）
Hexagon Socket
B
Machine Screws
4
（ M8*15mm ）
C
Gasket
20
Self-Drilling Screw
D
0
（ M4*15mm ）
E
Wrench
1
Mechanical
F
0
Adjustment Foot
G
TotaL 2 page; page 1
Spare
quantity
1
1
2
10
0
2
