POVISON TS8059ADW200 Installation Instruction

1. Installation of base plate and back plate (method 1)
2.Installation of bottom plate and back plate (method 1)
(1.1)Put the screw into the back plate
and tighten the screw with pliers
Connecting the backplane
(2.1)Tighten the screw of the back plate
and align it with the hole connected
with the bottom plate. After inserting
it, use a spanner to turn the screw
fastener at the bottom of the bottom
plate anticlockwise until it is firm
Installation instruction
Connecting the base plate
TS8059ADW200 Installation
The number of people needed for
installation：2
①
Please read the manual carefully
before installing this product.
And strictly follow the
installation process
② Please take good care of this
manual for your next
installation
Parts list
Serial
Shape
number
A
B
C
D
E
F
Name Quantity
Hardware foot
2
Fastener
3
（ø35mm）
Screw
4
(M8*40mm)
Wood tip
8
（M8*30mm）
Hexagon socket
10
thread(M8*40mm)
inner hexagon spanner
2
TotaL 1 page; page 1
