- Page 1 Simple Life , Better Home User Manual ASSEMBLY INSTRUCTION PC002AH/PC002AL +1888 666 9122 customerservice@povison.com PovisonOfficial Povison povisonofficial Povison Povison Official Povison...
- Page 2 Parts List A 2PC B 2PC C 2PC Backrest (A) Side rail (B) Side rail (C) D 2PC E 1PC F 1PC Seat plate (D) Tabletop (E) Glass top (F) G 1PC H 4PC 39PC Shelf (G) Leg (H) Washer (a) M6*40 f M6*16 g M6*30...
- Page 3 Parts List of Coffee Table G 1PC F 1PC E 1PC f M6*16 g M6*30 H 4PC 39PC Installation steps Note: medium screws (g)and short screws (f) are for coffee table. 1. Install tabletop (E) and leg (H): Connect tabletop (E) and leg (H) with the short screw (f) and washer (a).
- Page 4 2. Install tube G: connect leg (H) with screw(g) and washer (a). 3. Turn the table over; Test the overall stability and the stability between the leg (H) and the ground.
- Page 5 4. Place glass top (F): fix glass top F with 4 suction cups on the top of tabletop (E). Parts list of Single Chair A 2PC B 2PC D 2PC C 2PC M6*40 Allen Key Cushion 39PC 24PC...
- Page 6 Installation steps Note: long screws (b) are for chair 1. Install backrest A and side rail B: Connect backrest A to side rail B by long screw (b) and washer (a). 2. Combine backrest A to side rail C by long screw (b) and washer (a).
- Page 7 3. Install the seat plate D: combine seat plate D to side rail B\C respectively by long screw (b) and washer (a). 4. Place the cushion: Put the cushion above the seat plate D. Follow the installation steps above to assemble another chair (Full effect)
