AN224434
Clock configuration setup in TRAVEO
T2G Body
™
High family

About this document

Scope and purpose
This application note describes how to set up various clock sources in TRAVEO
T2G Body High family MCUs
™
and provides examples including configuring phase locked loop/frequency locked loop and calibrating the
internal low-speed oscillator.
Intended audience
This document is intended for users who use the clock configuration setup in TRAVEO
T2G Body High family.
™
Associated part family
TRAVEO
T2G Body High family
™
Application note
Please read the sections "Important notice" and "Warnings" at the end of this document
002-24434 Rev. *E
www.infineon.com
2024-04-23
