FORENO SLT032 Manual

Solitaire Shower Mixer
Black/Chrome
SLT032
9 421027 594531
Congratulations on your purchase of this high quality product from Foreno Tapware.
Please read the following before installation and retain (along with your receipt) for future reference.
TECHNICAL SPECIFICATIONS
Suitable for All Pressures
Minimum Pressure = 35kPa
Maximum operating Pressure = 500kPa
Maximum operating Temperature = 65 deg. Celsius
For domestic use only.
CONFIGURATION
Mains Pressure systems Prior to installation, remove the valve inserts from both inlets.
Unequal Low systems
Equal Low systems
INSTALLATION
Installation must comply with Section 5.4 of AS/NZS 3500 Standard with regard to Isolating stop cock use. Shower
mixers must be water tested with the outlet open, to prevent damage to cartridge seals; due to back pressure.
All pipe work must be flushed prior to the installation of this mixer, accessible inline filters must be installed in the
pipework for both the hot and cold inlet supply to prevent particles from damaging the ceramic cartridge.
Back Flow Prevention: Where back flow prevention is required, install our Back Flow Prevention Valve at the supply
elbow hose connection of the handpiece.
Any water seepage ex- the cartridge cavity opening can be stopped by retightening the large brass retaining nut.
FORENO TAPWARE (NZ) LTD | Freephone: 0508 FORENO | info@foreno.co.nz | 5 Hewlett Street, Port Whangarei 0110 | FORENO.CO.NZ
Install as supplied.
Important note: Only slide showers that are equipped with a large internal bore hose and open flow single
function handset will work effectively with this shower mixer. We recommend this mixer be used with a
Foreno Black Edition Slide Shower (SBK040) for optimum performance. If the cold pressure exceeds 500kPa,
or the pressure difference is greater than 10/1 ratio (i.e. 400kPa cold and 35kPa hot), we recommend
installing the needle valve (not supplied) preferably directly to the cold water feed port on the shower mixer
or alternatively anywhere on the cold feedline pipe.
Prior to installation, remove the valve inserts from both inlets.
