Page 3
Welcome to the world of Newline. Thank you for choosing the Newline X series Collaboration Touch Screen. Please use this document to get the most out of your screen. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Symbol Conventions Symbols are used in this document to indicate operations that need particular attention. The symbols are defined as follows: Provides additional information to supplement operation in the main NOTE text. Indicates a potentially hazardous situation that, if not avoided, could result in equipment damage, data loss, performance deterioration, or CAUTION unanticipated results.
Page 5
The voltage/current of the rear power output port is 5 V/2 A (maximum). Purchase the power code/AC adapter according to customer needs. The port can be used for Newline Android box X10D. Please do not connect any products with different power requirement. Otherwise, it may cause damage to products or fire.
Page 6
WARNING Do not touch the power cable with wet hands. CAUTION Do not install the product in high temperature environments. Do not install the product near a heat source, such as a radiator, a heat ● reservoir, a stove or other heating products. Do not expose the product to direct sunlight, which may cause high ●...
Page 7
CAUTION The power cable in the accessory box is for this product only. Do not use it on ● other products. Additional advice: Use the product in an environment with comfortable lighting. It is harmful to your ● eyes to watch in a too bright or too dark environment. Relax your eyes after a period of time for watching.
Parts and Functions Parts Front View ◆ Rear View ◆ X9/X8...
Page 9
Front Ports Camera Indicator (Bottom) Front Buttons Speakers Microphone Array Power Switch Power Supply Plug Top Camera Rear Ports Camera Indicator (Top) Remote control receiver Internal PC Port (OPS) Bottom Camera...
The voltage/current of the rear power output port is 5V/2A (maximum). Purchase the power code/AC adapter according to customer needs. The port can be used for Newline Android box X10D. Please do not connect any products with different power requirement. Otherwise it may...
Page 11
USB2.0 Embedded X9/X8 Tip: You are advised to connect X10D to HDMI rear 2.
Front Buttons ◆ Buttons Operations Functions Indicator LED Status Steady on red: shut down ● Short press Power on/off modes Steady on white: working state ● Decrease the Short press sound volume Decrease the Long press for more sound volume than 1 second continuously Steady on white: receiving...
Buttons Functions Buttons Functions Toggle Display Backlight Power On/Off Mode (including Standard and ECO modes) Switch Source to Internal PC Switch Source to DisplayPort Mute/Unmute Audio Open the External Source Mute/Unmute Microphone Menu (Short Press) Screen Lock (Long Press for More than 2 Seconds) Confirm/OK Up/Down/Left/Right Return to Previous/Exit...
Installation Guide Safety Precautions Installation Environment ◆ Keep Temperature Below 120 F ( ≤50 c) Keep Away From Do Not Use Combustible Vapors Outdoors (gas leaks, etc.) Installation Direction ◆ Hang the Product Horizontally No Vertical Installation Do Not Install Tilted Do Not Lay Flat...
Installation Height ◆ Recommended installation height from the floor to the bottom of the screen: 700 mm/27.6 in (X9), 730 mm/28.7 in (X8), 860 mm/33.9 in (X6) X9: 700 mm/27.6 in X8: 730 mm/28.7 in X6: 860 mm/33.9 in Installation Precautions Weight Loading ◆...
Vertical installation ◆ When installing, try to keep the product vertical. The vertical tilt range allowing for wall- mount installation is ±3 degrees. Excessive tilt angle may cause the screen glass to fall off or the product to collapse. Note For any problem, please contact our support desk.
Installation The dimensions of the four bracket mounting holes on the back panel are VESA MIS-Fcompliant (X9 or X8: 800 x 400 mm/31.50 x 15.75 in; X6: 600 x 400 mm/23.62 x 15.75 in). Use metric M8 screws with length of 10 mm to 15 mm (0.40 to 0.59 in) to secure the touch screen with the mounting system.
Installing the Internal PC (Optional) CAUTION The internal PC does not support hot plugging. Therefore, you must insert or remove it when the screen is powered is off. Otherwise, the screen or internal PC may be damaged. You will need to purchase the internal PC separately. Perform the following steps to install the internal PC.
Turning On/Off Power On Step 1: Plug the power supply into the power outlet fully and plug the power connector into the side of the product. Ensure the power is in the range of 100V to 240V with frequency at 50 Hz/60 Hz ± 5%. The power current must be grounded. Note The power outlet should be installed near the equipment and shall be easily accessible.
Page 20
If there is whiteboard data or screenshot(s), store your meeting documentations ● before powering off the touch screen. Otherwise, the product will delete your meeting documentations after the meeting is complete. Press the power button on the front panel or the power button on the remote control.
Operating the Touch Screen Start Screen When the product is turned on, the product will show the start screen page. As shown in the following figure. Home Touch the screen to start a meeting, and the product will go to the Home page. As shown in the following figure.
The first time you turn the screen on, only the cable connections appear in Connection. ● Wireless connection can be added in the Newline Extension setting. In this case, the name and icon of the HDMI Rear on the left cabled channel change as the Trucast application is enabled or an external product is connected.
Page 23
Side Toolbar ◆ The Annotation Mode/Discussion Mode/Home/Return/Windows icons are displayed by default in the toolbar at two sides of the screen. The bottom side tool bar can be customized as your choice (The default icon is Windows). You may also hide the side tool bar at the setting or move it up and down, shrink or expand by gestures.
Page 24
Icon Functions Short press: Go to the internal PC source. Long press: Unfold level-2 icons. Manage currently running applications. Slide left/right the currently running application or click “×” at the upper right corner to close the application. Enter the favorite source. View all gadgets.
Step 2: Click the icons on top to switch the list between Windows programs, external signal sources, and pre-installed gadgets. Click to view the Windows programs that the Newline Assistant uploads to ● the Smart system. For details,see "Add Quick Start Windows Programs in Smart System".
Newline Assistant Introduction ◆ Newline Assistant is the tool used as a bridge between smart system and Internal PC (OPS). It helps to add windows software to smart system as well as to protect USB data/ camera when switching between sources.
Add Quick Start Windows Programs in Smart System ◆ Step 1: In Windows, run the Newline Assistant program and drag the software icons or folder shortcut icons that you want to add from desktop or menu to the Newline Assistant window. The applications added or deleted through the Windows system will be automatically updated to the smart system until the upload progress reaches 100%.
Page 28
Note By default, the Newline Assistant application is added on the tab. Step 4: Tap the icon and add the shortcut at the Home page. Tap again and remove it. Step 5: Return to Home page. Click the icon of an added Windows application to start...
Quick Setting Menu Using two fingers to swipe up from the bottom of the screen, the quick setting menu will then show up, as shown in the following figure. Icon Functions Drag the slider to adjust the brightness. Drag the slider to adjust the sound volume. Click the icon to mute/unmute.
Page 30
More Information For more information Please visit our website (www.newline-interactive.com) for detailed instruction manual. Contact Us for Support Please email us at support@newline-interactive.com. Our company is devoted to product innovation and technology enhancement. Therefore, we may change product specs and...
