Summary of Contents for NewLine Trutouch X7
- Page 1 Unified Collaboration Touch Screen Quick Start Manual...
- Page 2 Thanks for purchasing this product. Please read the instructions carefully before using this product. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 3: Parts And Functions
Parts and Functions Parts Front Elevation ◆ Rear Elevation ◆ Camera Indicator General Power Switch Front Ports Bottom Camera AC Power Speakers Camera Indicator Internal PC Microphone Array Top Camera Front Buttons Ports in the Back Panel... - Page 4 Ports Front Ports ◆ HDMI...
-
Page 5: Rear Ports
Rear Ports ◆ HDMI High Speed USB Device AUDIO LINE OUT USB 3.0 SD CARD WIFI Antenna HDMI OUT RS-232 Touch Port HDMI Rear Touch Port VGA IN AUDIO IN RS-232 Central Control HDMI AUDIO... -
Page 6: Front Buttons
Front Buttons ◆ Buttons Operations Functions Short press Power on/off Short press Decrease volume Long press for more than 1 second Decrease volume continuously Short press Increase volume Long press for more than 1 second Increase volume continuously Short press Open the menu Short press Go to the home page... -
Page 7: Remote Control
Remote Control Button Function Button Function Power On/Off Switch Source to Internal PC Start the Default UC Programs Toggle Display Mode Mute Zoom In (PC) Microphone Mute Zoom Out (PC) Confirm/OK Up/Down/Left/Right Return to Previous/Exit Go to the Home Page Open the Menu Decrease Volume Increase Volume... -
Page 8: Safety Precautions
Installation Safety Precautions Installation Environment ◆ Keep Temperature Below 120 Degrees Fahrenheit Keep Away From Do Not Use Combustible Vapors Outdoors (gas leaks, etc.) Installation Direction ◆ Hang the Unit Horizontally No Vertical Installation Do Not Lay Flat... -
Page 9: Installation Height
Installation Height ◆ Recommend installation height is 33" (838mm) from the floor to the bottom of the screen. Installation Precautions Weight Loading ◆ The back of the panel is equipped with holes in VESA standard. Please use a VESA ● mounting system. - Page 10 Ventilation ◆ Ensure adequate ventilation and/or air conditioning environment. We recommend to keep certain distance from the side of the unit to the wall or panels. Ventilation requirement is showed in following figure. Right≥100mm Left≥100mm Installation The dimensions of the 4 bracket mounting holes in the back panel is VESA MIS-F compliant (400 x 400mm).
- Page 11 4-M8 1589 Unit: mm...
-
Page 12: Turning On/Off
Turning On/Off Power On Step 1: Plug in the power plug to the power outlet, and plug in the power connector to the side of the unit. Please ensure the power is in the range of 100V-240V with frequency at 50Hz/60Hz ±5%. The power current must be grounded. Step 2: Turn on the general power switch located on the side of the unit. -
Page 13: System Applications
System Applications When the unit is turned on, it will show the Meeting Start page. From here, the user can touch the screen to start a meeting, and the unit will go to the Home page. See the following figures. Figure 1 Meeting Start Page Figure 2 Home Page... - Page 14 Collaboration ● The user can touch here to start the default UC programs, or touch the small triangle to set three shortcuts for frequently used UC programs. The default UC program is the one used last time. Whiteboard ● The Whiteboard provides whiteboard and screen annotation functions. Sources ●...
- Page 15 Easy Setting Menu The easy setting menu can be accessed by sliding one finger down from the top of the screen.
- Page 16 More Information For more information Please visit www.newline-interactive.com. Contact Us for Support Please email us at support@newline-interactive.com. Newline Interactive, Inc. 101 East Park Blvd. Suite 807 Plano, TX 75074 Tel: +1 (972) 468-9728 Fax: +1 (972) 422-4288 20302T5B4001010...
