  • Page 1 Collaboration Touch Screen User Manual Newline Interactive Inc. www.newline-interactive.com...
  • Page 2 Welcome to the world of TruTouch. Thank you for choosing TruTouch Xseries Collaboration Touch Screen. Please use this document to maximize your user experience. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 3: Table Of Contents

    4 Operating the Touch Screen ..................... 23   4.1 Home Page .................................. 23   4.2 Assistant Meeting................................ 25   4.2.1 Newline Assistant ..............................25   4.2.2 Switch Applications ..............................25   4.2.3 Add or Delete Applications ............................25   4.3 Whiteboard ................................. 30  ...

  • Page 4: Safety Instruction

    4.6.1 Manually End Meeting ............................42   4.6.2 Automatically End Meeting ............................. 43   4.7 Shortcut Settings and Applications ..........................44   4.7.1 Shortcut Settings ..............................45   4.7.2 Applications ................................49   5 Serial Port Control ........................50   6 Specifications ..........................
  • Page 5 Put the product on a stable surface. An unstable surface includes and does not limited to an inclined plane, a shaky stand, desk or platform, which might cause the turnover and damage. Use the battery correctly. Galvanic corrosion, electric leakage and even fire may be caused by improper battery usage. ...
  • Page 6 Pull out the power plug during thunderstorms. Do not touch the product when lighting to avoid electric shock.  Install or place components which power supply voltage is high enough to cause personal  injury in places out of the reach of children. Do not cover or block up any vents on the product.
  • Page 7 Advice for watching: Use the product in an environment with comfortable light. It is harmful to your eyes to watch  in a too bright or too dark environment. Relax your eyes after a period of time for watching.  When you are watching, the distance which is 3 to 7 times of the screen height should be ...

  • Page 8: Overview

    Overview 1.1 Introduction The Collaboration Touch Screen adopts the advanced capacitive touch technology and All in One design, and integrates video, audio, touch, writing, and multi-media presentation functions. This product does not need additional devices, installation and wiring, and commissioning and maintenance. Dedicated software is customized for the assistant meeting.
  • Page 9 The top and bottom cameras cannot be used at the same time.  The indicators of the top and bottom cameras are turning white when in use and off when not in use.  Rear Elevation...

  • Page 10: Ports

    1.3 Ports Front Ports...
  • Page 11 Rear Ports Front Buttons...
  • Page 12 Buttons Operations Functions Power on/off   Short press Short press Decrease volume Long press for more than Decrease volume continuously 1 second Short press Increase volume Long press for more than Increase volume continuously 1 second Short press Open the menu  ...

  • Page 13: Remote Control

    1.4 Remote Control Buttons Functions Power On/Off Start the Default UC Programs Mute Microphone Mute Up/Down/Left/Right Confirm/OK...
  • Page 14 Buttons Functions Return to Previous/Exit Go to the Home Page Open the Menu Switch to Top Camera Switch to Bottom Camera Increase Volume Decrease Volume Settings Switch Source to HDMI Front Switch Source to HDMI Rear Switch Source to VGA Switch Source to Internal PC Page Up Page Down...

  • Page 15: Installation Guide

    Installation Guide 2.1 Safety Precautions Installation Environment...

  • Page 16: Installation Precautions

    Installation Direction Installation Height 2.2 Installation Precautions Weight Loading The back of the panel is equipped with holes in VESA standard. Please use a VESA  standard mounting system. When using a mobile cart, please ensure the mobile cart has no less than 60kg loading ...

  • Page 17: Installation

    When using wall-mount bracket, please ensure the wall can support the weight of the  unit. We recommend that the wall surface is reinforced, and have a loading capacity twice the weight of the unit. Please consult a professional installer for wall-mount installation.

  • Page 19: Getting Started

    Getting Started 3.1 Power On Step 1 Plug in the power plug to the power outlet, and plug in the power connector to the side of the unit. Please ensure the power is in the range of 100V- 240Vwith frequency at 50Hz/60Hz ±5%.
  • Page 20 Step 2 Press the power button on the front panel or the power button on the remote control again. The Really end your meeting dialog box is displayed as follows. Step 3 In the Really end your meeting dialog box, click Yes. The meeting start page is displayed as follows.

  • Page 21: Positioning

    Step 4 Press the power button on the front panel or the power button on the remote control again to power off the panel. The power indicator turns off. Step 5 If you are not going to use the unit for an extended period of time, we recommend you to switch off the general power switch.
  • Page 22 Step 4 Select in the Tablet PC Settings window.
  • Page 23 Step 5 Use finger or pencil to click and hold the center of the flickering cross . Do not release it until moves to the next positioning point. Complete the calibration process as instructed. Step 6 After the calibration is complete, the Digitizer Calibration Tool dialog box is displayed. Click Yes to save calibration data.

  • Page 24: Operating The Touch Screen

    Operating the Touch Screen 4.1 Home Page When the unit is turned on, it will show the Meeting Start page. The user can touch the screen to start a meeting, and the unit will go to the Home page. See the following figures. Figure 4-1 Meeting Start page...
  • Page 25 Figure 4-2 Home Page Collaboration  The user can touch here to start the default UC programs, or touch the small triangle to set three shortcuts for frequently used UC programs. The default UC program is the one used last time. Whiteboard ...

  • Page 26: Assistant Meeting

    4.2 Assistant Meeting 4.2.1 Newline Assistant Introduction Newline Assistant is a tool used to obtain applications required by users on Windows system. On Android system, you can start Windows applications by clicking one button. Installation Step 1 Connect Internal PC correctly.
  • Page 27 Collaboration button, and users can fast start the added application by only clicking Collaboration. Add Applications on Windows System Step 1 Run the Newline Assistant application on Windows system, and select applications to be added in the displayed Newline Assistant window.
  • Page 28 Step 2 Click to return to the home page. Click the triangle at the upper right corner of Collaboration and select Add on the displayed menu. The customization page is displayed.
  • Page 29 Step 3 On the customization page, click to view all Windows applications added using Newline Assistant in Step 1.
  • Page 30 Step 4 Add applications on the page described in Step 3. In the application list displayed on the right area, click on the right of an application to add the application. A maximum of 3 applications (including Android and Windows applications) can be added.

  • Page 31: Whiteboard

    4.3 Whiteboard Writing or Annotation  On the whiteboard page, you can select pen type, width, and color to write or annotate. Also erase selected content or clear all contents. File management  Preview, select, copy or delete a file. To access the whiteboard meeting, click Whiteboard.

  • Page 32: Whiteboard Functions

    4.3.1 Whiteboard Functions New Slide and Settings Create a new slide  In writing mode, click to create a new slide. A maximum of 20 slides can be created. See the following figure. Slide settings  Click and hold to set the background color of new slides. See the following figure.
  • Page 33 Whiteboard Mode Click at the lower left corner of the whiteboard to switch whiteboard modes. : Annotation mode  The background is transparent and the real-time image of the current signal source is displayed. You can comment on presentation content such as Office documents and pictures as required.
  • Page 34 Pen Type On the whiteboard, two types of pens are supported: hard pen and highlighter. Their icons are Hard pen: used to write.  Highlighter: used to comment. Characters covered by comments are visible.  Line Type and Color On the whiteboard, click and hold .
  • Page 35 Screenshot In comment mode, click to save the current image as a picture, as shown in Figure 4-3. After the meeting is ended, save screenshots in the Save meeting discussion dialog box, as shown in Figure 4-4. Figure 4-3 Screenshot...
  • Page 36 Figure 4-4 Save meeting discussion Clear On the whiteboard page, click to clear all contents on the current writing slide, as shown in the following figure.

  • Page 37: Slide Operations

    Cancel On the whiteboard page, click to undo the latest operation, as shown in the following figure. 4.3.2 Slide Operations You can preview, select, and delete a created writing slide. Slide Preview Click at the lower right corner of the whiteboard. All writing slides are displayed. Click one slide to switch to the slide for other operations.

  • Page 38: Signal Source

    Slide Selection and Deletion Click . The buttons are displayed. You can select and delete a writing slide as required. See the following figure. Click the slide: to select the current slide.  Click : to select all slides.  Click : to delete selected slides.

  • Page 39: External Storage

    4.5 External Storage The product supports connection to external storage devices. On the external storage page, you can view files stored in all external storage devices (for example, the USB flash disk and SD card) and preview, select, copy, delete and search content in each storage device. 4.5.1 External Storage Page On the home page, click External Storage as shown in the following figure.

  • Page 40: File Preview

    4.5.2 File Preview By default, files saved to internal storage are displayed. You can click at the upper left corner to view all external storage devices connected to Android USB and preview a specified external storage device. See the following figure. 4.5.3 File Filtering For your convenience, the system displays files by category, for example, document, picture, audio and video.

  • Page 41: File Search

    4.5.4 File Search Click and enter the key word in the search box. Files matching the key word are listed. The system supports second filtering for searched files. Click the filtering tool bar below the search box to filter searched files based on PPT, PDF, DOC, XLS, Audio, and Video, as shown in the following figure.

  • Page 42: File Operations

    4.5.5 File Operations Click to perform operations on files in the storage, including select all files or one file, copy, delete and cancel, as shown in the following figure. Click the file: to select the current file.  All: Select all files. ...

  • Page 43: End Meeting

    4.6 End Meeting 4.6.1 Manually End Meeting On the home page, click . The Save meeting discussion page will be displayed. The meeting will be ended and timer will stop. File Naming Save slides created during the meeting and annotation screenshots on the meeting record page, as shown in the following figure.

  • Page 44: Automatically End Meeting

    Click No. The meeting continues and the system stays on the Save meeting − discussion page. If the meeting notes can’t be saved to USB drive or SD card successfully when ending meeting, please use USB drive or SD card smaller than 32GB and change the file system into FAT 32 format. 4.6.2 Automatically End Meeting If the period without operations on the screen exceeds 90 minutes, the system will lock the screen automatically to protect your privacy.

  • Page 45: Shortcut Settings And Applications

    4.7 Shortcut Settings and Applications Slide one finger down for 40 to 80 mm from the top of the screen, the Shortcut Settings and Applications pages are displayed. As shown in the following figure.

  • Page 46: Shortcut Settings

    4.7.1 Shortcut Settings After a top-down slide, the Shortcut Settings page is displayed by default, as shown in the following figure. Clock Settings Click to add the required time zone, and click Time Formats to set the time display mode (analog clock or electronic clock).

  • Page 47: Volume Adjustment

    Brightness Adjustment Drag the slider beside the icon to adjust the brightness. Volume Adjustment Drag the slider beside the icon to adjust the volume. Microphone Mute Mode Click to enable or disable the microphone mute mode.
  • Page 48 Wi-Fi Settings Click to enter the system settings page and select the Wi-Fi hotspot to be connected. Wired Network Settings Click to enter system settings page and set information about the wired network.
  • Page 49 Camera Settings Click to enter system settings page and set the default camera used by the display and anti-flickering information.

  • Page 50: Applications

    System Settings Click to enter system settings page. Setting items are shown in the following figure. 4.7.2 Applications In the assistant meeting, click Applications to fast select and start applications on Android system, and slide right and left on the screen to view all applications, as shown in the following figure.

  • Page 51: Serial Port Control

    Serial Port Control Connect RS-232 port to the PC or controlling device. Enable RS-232 serial port connection and complete the following configuration. Port: COM1 (Set according to PC or controlling device’s port number) Bit rate 19200 Odd/even None check Data bits Stop bit The following table lists the button controlling code and return code.
  • Page 52 Function Controlling codes Return codes 7F 08 99 A2 B3 C4 02 FF 01 0D CF 7F 09 99 A2 B3 C4 02 FF 01 0D 01 Page Up 7F 08 99 A2 B3 C4 02 FF 01 13 CF 7F 09 99 A2 B3 C4 02 FF 01 13 01 Page Down 7F 08 99 A2 B3 C4 02 FF 01 14 CF...
  • Page 53 Function Controlling codes Return codes Query the 7F 08 99 A2 B3 C4 02 FF 01 3D CF 7F 09 99 A2 B3 C4 02 FF 01 3D 01 firmware version number Set Display 7F 08 99 A2 B3 C4 02 FF 07 XX CF 7F 09 99 A2 B3 C4 02 FF 07 XX Mode 01 CF...
  • Page 54 Function Controlling codes Return codes Microphone 7F 09 99 A2 B3 C4 02 FF 01 45 status XX CF 7F 08 99 A2 B3 C4 02 FF 01 45 CF XX=01 indicates that the microphone  is mute. XX=02 indicates that the microphone ...

  • Page 55: Specifications

    Specifications Parameter Value Display Backlight Display Area 1209.6 x 680.4mm Active Screen Size 55" Display Ratio 16:9 Resolution 1920*1080Pixel Display Colors 8-bit, 16.7M colors Brightness 370nit Contrast 4000:1 Viewing Angle 178° Response Time Life Time 30000h Speaker Speaker Position Forward Rated Impedance 8Ω(±15%) Freq.
  • Page 56 >89% Haze Surface Hardness ≥8H Touch Technology True Flat HID support Touch Points 10 Points in Windows/5 Points in Android Writing Tools Newline Stylus or Finger Touch Resolution 19354x10866 Scan Speed 100Hz Positioning Accuracy Communication Interface USB-A Transportation/Storage Storage Temperature/Humidity...
  • Page 57 Parameter Value Working 0°C-40°C/10%-90% Temperature/Humidity Mounting (optional) Wall-mounted / Floor Stand Outline Dimension 1320×886×87mm Packing Dimension 1470×265×995mm Net Weight 36Kg Gross Weight 45Kg Ports Microphone(3.5mm)×1, HDMI×1, USB(Touch)×1, Front Interface Inputs USB(OPS)×1, USB(Android)×1 HDMI(MHL*)×1, VGA×1, USB(Touch)×2, Audio× AV Inputs AV Outputs 3.5mm Line out x 1, HDMI x 1 (only video) USB2.0×2, RS232×1, RJ45×1, USB3.0×1, SD Other...
  • Page 58 Parameter Value Android Software Input Resource Preview On Screen Annotation Discussion Board The above-mentioned specifications are for reference only. Newline may change the specs without additional notice. Contact local distributors for more details.

  • Page 59: More Information

    More Information For more information Please visit www.newline-interactive.com. Contact Us for Support Please email us at support@newline-interactive.com. Newline Interactive Inc. 101 East Park Blvd. Suite 807 Plano, TX 75074 Tel: +1 (972) 468-9728 Fax: +1 (972) 422-4288...

  • Page 60: Fcc Statement

    FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
