NewLine trutouch X7 User Manual

Collaboration touch screen
Hide thumbs Also See for trutouch X7:
Table of Contents

Advertisement

Quick Links

Collaboration Touch Screen
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the trutouch X7 and is the answer not in the manual?

Questions and answers

Related Manuals for NewLine trutouch X7

Summary of Contents for NewLine trutouch X7

  • Page 1 Collaboration Touch Screen User Manual...

  • Page 2: Before Using This Product

    Welcome: Thanks for purchasing this product. Please read the instructions carefully before using this product. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 3: Table Of Contents

    Contents About This Document Overview Inroduction Parts Ports Remote Control Installations Safety Precautions Installation Precautions Installation Preparation Power on Power off Position System Applications Home Page Assistant Meeting Whiteboard Signal Source External Storage End Meeting Shortcut Settings and Applications Serial Port Control Specifications More Information...

  • Page 4: About This Document

    About This Document Welcome to use the Collaboration Touch Screen. This document describes multiple functions, instructions and notes of the product. Before using the product, read this document carefully. Figures in this document are only for your reference. Symbols are used in this document to indicate operations that need particular attention. The symbols are defined as follows: Provides additional information to supplement operations in the main NOTE...

  • Page 5: Overview

    Overview Inroduction The Collaboration Touch Screen adopts the advanced capacitive touch technology and All in One design, and integrates video, audio, touch, writing, and multi-media presentation functions. This product does not need additional devices, installation and wiring, and commissioning and maintenance. Dedicated software is customized for the assistant meeting.

  • Page 6: Ports

    Rear Elevation ◆ Camera Indicator General Power Switch Front Ports Bottom Camera AC Power Speakers Camera Indicator Internal PC Microphone Array Top Camera Front Buttons Ports in the Back Panel Ports Front Ports ◆ HDMI...
  • Page 7 Rear Ports ◆ HDMI High Speed USB Device AUDIO LINE OUT USB 3.0 SD CARD WIFI Antenna HDMI OUT RS-232 Touch Port HDMI Rear Touch Port VGA IN AUDIO IN RS-232 Central Control HDMI AUDIO...
  • Page 8 Front Buttons ◆ Buttons Operations Functions Short press Power on/off Short press Decrease volume Long press for more than 1 second Decrease volume continuously Short press Increase volume Long press for more than 1 second Increase volume continuously Short press Open the menu Short press Go to the home page...

  • Page 9: Remote Control

    Remote Control Buttons Functions Buttons Functions Power On/Off Switch Source to Internal PC Start the Default UC Programs Toggle Display Mode Mute Zoom In (PC) Microphone Mute Zoom Out (PC) Confirm/OK Up/Down/Left/Right Return to Previous/Exit Go to the Home Page Open the Menu Decrease Volume Increase Volume...

  • Page 10: Installations

    Installation Safety Precautions Installation Environment ◆ Keep Temperature Below 120 Degrees Fahrenheit Keep Away From Do Not Use Combustible Vapors Outdoors (gas leaks, etc.) Installation Direction ◆ Hang the Unit Horizontally No Vertical Installation Do Not Lay Flat...

  • Page 11: Installation Precautions

    Installation Height ◆ Installation Precautions Weight Loading ◆ The back of the panel is equipped with holes in VESA standard. Please use a VESA ● stand mounting system. When using a mobile cart, please ensure the mobile cart has no less than 80kg ●...

  • Page 12: Installation

    Right≥100mm Left≥100mm Installation The dimensions of the 4 bracket mounting holes in the back panel is VESA MIS-F compliant (400 x 400mm). Please use the metric M8 screws with length of 10 to 15mm to secure the touch screen with the mounting system. Dimensions of the mounting holes in the back panel is shown in the next page.

  • Page 13: Preparation

    Preparation CAUTION Please peel off protection film before using the machine! Use only HB or softer pencil to write on the screen, Otherwise, the glass surface may be damaged! Power On Step 1: Plug in the power plug to the power outlet, and plug in the power connector to the side of the unit.

  • Page 14: Power Off

    Power Off Step 1: Press the power button on the front panel or the power button on the remote control. The Save meeting discussion page is displayed as follows. Step 2: Press the power button on the front panel or the power button on the remote control again.

  • Page 15: Position

    Step 4: Press the power button on the front panel or the power button on the remote control again to power off the panel. The power indicator turns off. Step 5: If you are not going to use the unit for an extended period of time, we recommend you to switch off the general power switch.
  • Page 16 Step 4: Select in the Tablet PC Settings window.
  • Page 17 Step 5: Use finger or pencil to click and hold the center of the flickering cross Do not release it until moves to the next positioning point. Complete the calibration process as instructed. To provide calibration samples, tap the crosshair each time that it appears on the screem.

  • Page 18: System Applications

    System Applications Home Page When the unit is turned on, it will show the Meeting Start page. From here, user can touch the screen to start a meeting, and the unit will go to the Home page. See the following figures. Figure 1 Meeting Start page Figure 2 Home page...

  • Page 19: Assistant Meeting

    Assistant Meeting Newline Assistant Introduction ◆ Newline Assistant is a tool used to obtain applications required by users on Windows system. On Android system, you can start Windows applications by clicking one button. Installation ◆ Step 1: Connect Internal PC correctly.
  • Page 20 Step 4: Log in to the website www.newline-interactive.com and choose Products > Software to download Newline Assistant installation package. Step 5: Install Newline Assistant as instructed. Switch Applications On the home page, click Collaboration to start applications used last time, or click the triangle at the upper right corner of Collaboration to open the application list and select current applications to start the collaboration meeting.
  • Page 21 Collaboration. Add Applications on Windows System ◆ Step 1: Run the Newline Assistant application on Windows system, and select applications to be added in the displayed Newline Assistant window. Step 2: Click to return to the home page. Click the triangle at the upper right corner of Collaboration and select Add on the displayed menu.
  • Page 22 Step 3: On the customization page, click to view all Windows applications added using Newline Assistant in Step 1. Step 4: Add applications on the page described in Step 3. In the application list displayed on the right area, click on the right of an application to add the application.

  • Page 23: Whiteboard

    Delete Applications ◆ On the application customization page, click at the upper right corner of an application to delete the application. After an application is deleted successfully, restores to Whiteboard Writing or Annotation ● On the whiteboard page, you can select pen type, width, and color to write or annotate. Also erase selected content or clear all contents.
  • Page 24 Whiteboard Functions New Slide and Settings ◆ Create a new slide ● to create a new slide. A maximum of 20 slides can be In writing mode, click created. See the following figure. Slide settings ● Click and hold to set the background color of new slides. See the following figure.
  • Page 25 Whiteboard Mode ◆ Click at the lower left corner of the whiteboard to switch whiteboard modes. : Annotation mode ● The background is transparent and the real-time image of the current signal source is displayed. You can comment on presentation content such as Office documents and pictures as required.
  • Page 26 Line Type and Color ◆ On the whiteboard, click and hold . The line type and color selection page is displayed. You can select the line type and color for writing. See the following figure. Eraser ◆ Two methods are available to erase written errors or content as follows: Five-finger gesture: touch the screen with five fingers at the same time.
  • Page 27 Figure 3 Screenshot Figure 4 Save meeting discussion...
  • Page 28 Clear ◆ On the whiteboard page, click to clear all contents on the current writing slide, as shown in the following figure. Cancel ◆ On the whiteboard page, click to undo the latest operation, as shown in the following figure. Slide Operations You can preview, select, and delete a created writing slide.
  • Page 29 Note Only 8 slides are displayed in each column, and the remaining slides are displayed in the second column. You can slide one finger right or left to switch columns. Slide Selection and Deletion ◆ Click . The buttons are displayed. You can select and delete a writing slide as required.

  • Page 30: Signal Source

    Signal Source On the home page, click Sources. The signal source selection page is displayed. You can preview the image of the corresponding signal channel, as shown in the following figure. If the channel has no signal input, No Signal is prompted. You can click the selected signal source to switch to the corresponding channel in full screen.
  • Page 31 File Preview By default, files saved to internal storage are displayed. You can click at the upper left corner to view all external storage devices connected to Android USB and preview a specified external storage device. See the following figure. File Filtering For your convenience, the system displays files by category, for example, document, picture, audio and video.
  • Page 32 File Search Click and enter the key word in the search box. Files matching the key word are listed. The system supports second filtering for searched files. Click the filtering tool bar below the search box to filter searched files based on PPT, PDF, DOC, XLS, Audio, and Video, as shown in the following figure.

  • Page 33: End Meeting

    File Operations Click to perform operations on files in the storage, including select all files or one file, copy, delete and cancel, as shown in the following figure. Click the file: to select the current file. ● All: Select all files. ●...
  • Page 34 File Storage ◆ When no external USB flash disks and SD cards are connected, icons in the Save to area are in gray. When an external USB flash disk or SD card is connected, icons in the Save to area will turn into blue. Click the USB or SD card icon in blue. The system stores selected pictures to the uc folder under the root folder of the corresponding USB flash disk or SD card.
  • Page 35 Automatically End Meeting If the period without operations on the screen exceeds 30 minutes, the system will lock the screen automatically to protect your privacy. If the period without operations exceeds 60 minutes, the system will delete all meeting contents automatically, as shown in the following figure.

  • Page 36: Shortcut Settings And Applications

    Shortcut Settings and Applications Slide one finger down for 40 to 80 mm from the top of the screen, the Shortcut Settings and Applications pages are displayed. As shown in the following figure. Shortcut Settings After a top-down slide, the Shortcut Settings page is displayed by default, as shown in the following figure.
  • Page 37 Brightness Adjustment ◆ Drag the slider beside the icon to adjust the brightness. Volume Adjustment ◆ Drag the slider beside the icon to adjust the volume.
  • Page 38 Microphone Mute Mode ◆ Click to enable or disable the microphone mute mode. Wi-Fi Settings ◆ Click to enter the system settings page and select the Wi-Fi hotspot to be connected.
  • Page 39 Wired Network Settings ◆ Click to enter system settings page and set information about the wired network. Camera Settings ◆ Click to enter system settings page and set the default camera used by the display and anti-flickering information.
  • Page 40 System Settings ◆ Click to enter system settings page. Setting items are shown in the following figure. Applications In the assistant meeting, click Applications to fast select and start applications on Android system, and slide right and left on the screen to view all applications, as shown in the following figure.

  • Page 41: Serial Port Control

    Serial Port Control Connect RS-232 port to the PC or controlling device. Enable RS-232 serial port connection and complete the following configuration. Port: COM1 (Set according to PC or controlling device’s port number) Bit rate 19200 Odd/even check None Data bits Stop bit The following table lists the button controlling code and return code.
  • Page 42 Function Controlling codes Return codes 7F 08 99 A2 B3 C4 02 FF 01 18 7F 09 99 A2 B3 C4 02 FF 01 18 VOL + 01 CF 7F 08 99 A2 B3 C4 02 FF 01 1B 7F 09 99 A2 B3 C4 02 FF 01 1B Menu 01 CF 7F 08 99 A2 B3 C4 02 FF 01 1C...
  • Page 43 Function Controlling codes Return codes 7F 08 99 A2 B3 C4 02 FF 07 XX Set Display 7F 09 99 A2 B3 C4 02 FF 07 XX Note: Mode 01 CF XX indicates the mode. 00, 01, 02 and 03 indicate standard, bright, soft and custom modes respectively.

  • Page 44: Specifications

    Specifications Parameter Value Display Backlight Display Area 1538.88 x 865.62mm Active Screen Size 70" Display Ratio 16 : 9 Resolution 1920 x 1080Pixel Display Colors 10bit Brightness 350cd/m2 (Max) Contrast 4000 : 1 Response Time Life Time 50000h Speaker Speaker Position Forward Rated Impedance 8Ω...
  • Page 45 Parameter Value Camera Top x 1 & Bottom x 1 (Only one can use in the Position same time) Sensor 2M Pixels Lens 86° Video Resolution 1920 x 1080@30fps (Max) Frame Rate 30fps/60fps Electrical Maximum < 250W Power Consumption Standby Mode ≤ 0.5W Working Voltage AC 100V –...
  • Page 46 4 / 2 HDMI Out 1 x 10/100/1000M Microphone in Line Out SPDIF Out Build-in WIFI 802.11b/g/n Windows 8.1/Windows 10 The above-mentioned specifications are for reference only. Newline may change the specs without additional notice. Contact local distributors for more details.

  • Page 47: More Information

    More Information For more information Please visit www.newline-interactive.com. Contact Us for Support Please email us at support@newline-interactive.com. Newline Interactive Inc. 101 East Park Blvd. Suite 807 Plano, TX 75074, USA Tel: +1 (972) 468-9728 Fax: +1 (972) 422-4288...
