2.5.2 Tower Kit Wiring - TWR Lighting E-1DBSL Manual

DUAL MEDIUM INTENSITY LED/STROBE

2.5.2 Tower Kit Wiring

M.E-2018.E-1DBSL
11-11-08 REV 1-19-18
MODEL E-1DBSL
2.5.1.2 Level the STLDBEACON2A using the spirit level at the base of
the lens. Shims may be used under beacon base or triple nutting
each bolt with palnuts on all four (4) nuts.
2.5.1.3 Slip the electrical cable for the STLDBEACON2A through the
watertight connector (cable gland bushing), and tighten the gland
nut to make a watertight seal. Attach the wires to the terminal
strip as follows:
Connect Cable
Wire Color
10 Gauge Red
14 Gauge White/Green
16 Gauge Brown
16 Gauge Blue
10 Gauge Black
14 Gauge White
14 Gauge Green
10 Gauge Red/Black
16 Gauge Bare Wire
Install wiring between the controller and the beacon utilizing strobe cable.
(TWR LIGHTING CANNOT WARRANTY SYSTEMS THAT
EMPLOY SPLICING CABLE.) Refer to drawings HDO-264, and 602, for
installation of light kits. Following these minimum guidelines, as well as any
local or end user additional requirements, installing light kits will require
lifting of the cable by the supplied cable grip or conduit to affix to the tower.
Always work safely and adhere to all OSHA Safety Guidelines when lifting
wiring or working on the structure or tower itself. It is the installer's
responsibility to install the lighting kit in a safe manner. Installers can
request from OSHA their requirements 29CFT 1926.21, and 29CFR
1926.105, to ensure compliance to regulations.
NOTE: On occasion, a set of custom lighting kit drawings may be
specifically requested by a customer and installed in this manual. In cases
such as this, the drawings will precede the manual if a conflict occurs.
To Lamp platform
Match Wire Color
16 Gauge Red
16 Gauge White/Green
16 Gauge Brown
16 Gauge Blue
16 Gauge Black
16 Gauge White
16 Gauge Green
16 Gauge Red/Black
Beacon Base
Terminal
Block Number
1
2
3
4
5
6
7
8
5
