DUAL MEDIUM INTENSITY LED/STROBE
M.E-2018.E-1DBSL
11-11-08 REV 1-19-18
MODEL E-1DBSL
All the necessary information for wiring the STLDBEACON2A and
sidelights is contained on the tower kit drawing 602. The connections for the
STLDBEACON2A and sidelights in the controller are as follows:
2.5.2.1 Connect
STLDBEACON2A wiring to TB1-1.
2.5.2.2 Connect the 10 gauge BLACK wire from STLDBEACON2A
wiring to TB1-2.
2.5.2.3 Connect the 14 gauge WHITE wire from STLDBEACON2A
wiring to TB1-3.
2.5.2.4 Connect the 16 gauge BROWN wire from STLDBEACON2A
wiring to TB1-4.
2.5.2.5 Connect the 16 gauge BLUE wire from STLDBEACON2A
wiring to TB1-5.
2.5.2.6 Connect the 10 gauge RED wire from STLDBEACON2A wiring
to Fuse Block marked "B."
2.5.2.7 Connect
STLDBEACON wiring to TB1-11.
2.5.2.8 Connect the 14 gauge GREEN wire from STLDBEACON2A
ground back panel.
2.5.2.9 Connect the NEUTRAL wire from sidelight wiring to TB1-12.
2.5.2.10 Connect the RED wire from the sidelight wiring to Fuse Block
marked "S."
2.5.2.11 Connect the ground wire (if cable is used) from sidelight wiring to
ground screw left of TB1.
the 10 gauge
the 14 gauge WHITE/GREEN
RED/BLACK wire
wire
from
from
