TWR Lighting E-1DBSL Manual page 45

4
B
2
A
DATE REV AUTHOR
11/07/14
E JZAMORANO REM. WIRE CONNECT
4
3
1
DRAWN
gsebek
CHECKED
QA
MFG
APPROVED
DESCRIPTION
3
2
ITEM QTY PART NUMBER
1 1 OL1VLED2
1.1 1
100588_RE
*
1.2 1 100591
*
1.3 1 100680
*
1.4 1 A10290
*
1.5 6 STD05008
*
1.6 1 OLG
*
1.7 1 AP100846
*
1.8 1 106V
*
1.9 6 STE01-047
*
1.10 16 18PRSS
*
1.11 1 PS90-260/24
*
1.12 1 20RED
*
1.13 2 WIRENUTBLU
*
2 2 HC255SS
3 1 7X7SS
4 2 12V245
5 1 105V
6 2 832X14PH
7 2 A1A
8 1 A314
* = ITEMS NOT SHOWN
7
6
3
4
5
8
* GROUND WIRE MUST BE CONNECTED
TO PROPERLY PROTECT POWER SUPPLY.
FAILURE TO GROUND WILL VOID ALL
WARRANTIES.
8/18/2004
TITLE
OL1VLED2 120-240VAC FAA-OL16LED
(L810 OBSTRUCTION LIGHT)
SIZE
B
SCALE
2
1
Parts List
DESCRIPTION
L810 OBSTRUCTION LIGHT
OL 6LED BASE PLATE
OL 6LED STAR DISK
OL1/2 SERIAL # LABEL
5/32" ID RUBBER GROMMET
LED EMITTER
OL GASKET
SIDELIGHT LENS CLEAR ACYRLIC
LENS HOLDER RING
LED VERTICAL PCB
1/8 X .45 SS POP RIVET
POWER SUPPLY
#20AWG RED BELDON WIRE
BLUE WIRE NUT
SIDELIGHT LATCH
1/16 HOL 7X7 S.S. WIRE
OL LENS CLIP
SINGLE SIDELIGHT BODY
8-32 X 1/4 PH SS SLOT SCREW
STAKON CRIMP
3/4" CONDUIT LOCKNUT GALV.
7.342
5.30
FIXTURE
120-240VAC
SCHEMATIC
DWG NO
100656i
1 1
SHEET OF
1
B
A
REV
E
