DUAL MEDIUM INTENSITY LED/STROBE
2.4.4 Connect the AC ground to the ground stud to the lower right of the terminal
2.4.5 Controller panel should be connected to the tower and/or building grounding
2.5

TOWER LIGHTING KIT

When installing this system, the customer will need to use strobe cable wiring
method to wire the STLDBEACON2A. Refer to tower kit drawing 602, for cable
installations.
THIS SYSTEM OPERATES AT HIGH VOLTAGE LEVELS THAT COULD
BE LETHAL TO SERVICE PERSONNEL. ALL INSTALLATION AND
MAINTENANCE WORK SHOULD BE DONE BY QUALIFIED SERVICE
PERSONNEL ONLY. WHEN PERSONNEL IS INSTALLING SYSTEM OR
PERFORMING MAINTENANCE ON THIS SYSTEM, MAKE SURE THE
POWER IS TURNED OFF AT THE SERVICE BREAKER PANEL!!
READ AND UNDERSTAND THE THEORY OF OPERATION AND ITS
SAFETY MESSAGES BEFORE ATTEMPTING INSTALLATION/MAIN-
TENANCE OF THIS SYSTEM. DO NOT ATTEMPT TO DEFEAT THE
INTERNAL SAFETY SWITCHES IN THE CONTROLLER AND
STLDBEACON2A!!
2.5.1 LED Red Beacon Mounting and Wiring (Refer to Drawings HDO-264,
M.E-2018.E-1DBSL
11-11-08 REV 1-19-18
MODEL E-1DBSL
block TB1.
system with the exception of installations on AM RF applications where
controller grounding to earth ground is prohibited. Ground the controller
only to the tower itself using a suitable RF ground.
WARNING DANGER!!!
and INS-264)
2.5.1.1 Bolt the STLDBEACON2A to the mounting plate using four 5/8"
x 1 1/4" galvanized bolts that are supplied. Installer should make
sure to check for full thread engagement on Anco locknut. Allow
16" clearance in back of the hinge (25" from the center of the base)
to tilt lens back without hitting an obstruction.
