DUAL MEDIUM INTENSITY LED/STROBE
2.6

ALARM WIRING

Individual alarm contacts (Form C) are provided for strobe failures, power failure,
and photocell on. It is left up to the customer or installer on how they choose to
utilize these contacts with their monitoring equipment.
equipment is available. Please inquire within the sales staff at the factory for models
available and pricing. Alarm configurations are shown on drawings H40-264, and
M01-264.

2.6.1 White Strobe Failure (SF)

2.6.2 Lights On (LO) – Nighttime

2.6.3 Power Failure (PF)

2.6.4 LED Red Beacon Burnout (BB)

2.6.5 Sidelight Failure (SL)

M.E-2018.E-1DBSL
11-11-08 REV 1-19-18
MODEL E-1DBSL
Connect the customer's alarm common to plug P12, terminal #5. Connect the
customer's alarm wire to plug P12, terminal #6, for normally open (or)
terminal #4, for normally closed monitoring.
Connect the customer's alarm common to plug P12, terminal #2. Connect the
customer's alarm wire to plug P12, terminal #1, for normally open (or)
terminal #3, for normally closed monitoring.
Connect the customer's alarm common to plug P12, terminal #11. Connect
the customer's alarm wire to plug P12, terminal #12, for normally open (or)
terminal #10, for normally closed monitoring.
Connect the customer's alarm common to plug P12, terminal #8. Connect the
customer's alarm wire to plug P12, terminal #7, for normally open (or)
terminal #9, for normally closed monitoring.
Connect the customer's alarm common to plug P12, terminal #14. Connect
the customer's alarm wire to plug P12, terminal #15, for normally open (or)
terminal #13, for normally closed monitoring.
External monitoring
