TWR Lighting E-1DBSL Manual page 26

DUAL MEDIUM INTENSITY LED/STROBE
6.0 MAJOR COMPONENTS LIST (continued)
PART NUMBER
SPM-120
(This replaces the
DTK-120HW)
STH03264A
6390 – FAA2
(This replaces the
P2455L Photocell)
KTK1
KTK2
PF-250
(This replaces the
FS15530T Flasher)
TS14130
STA08018
STA08015
STA08010
STJ01004
STC05004
STC30018
TERMBLK-12
TERMBLK 141 – 12
STJ10008
STLDBEACON2A
M.E-2018.E-1DBSL
11-11-08 REV 1-19-18
MODEL E-1DBSL
DESCRIPTION
SURGE ARRESTOR 120V AC
RELAY PCB w/ALARM LOCKOUT
ELIMINATION MODIFICATION
120 - 240V PHOTOCELL
1 amp FUSE
2 amp FUSE
FLASHER SOLID STATE
TIMER
150 ohm 100W
35k 20W
2.4 meg 2W
SPDT 15 amp SWITCH
ISOLATION TRANSFORMER
FERRORESONANT
TRANSFORMER
12 PART TERM BLK
12 PART TERM BLK
THERMAL LIMITING SWITCH
STROBE LED BEACON
SCHEMATIC TAG #
MOV1
PCB #3
PHOTOCELL
F4
F5
M3
M4
R31
R32
R33
SW3
T2
T1
TB1
TB2
TLS
22
