- Page 1 Owner’s Manual M O D E L S E S T / E S T T A L L INSTALLATION & OPERATION Rev 1.05C 08-27-19 C M A D I S H M A C H I N E S 1 2 7 0 0 K N O T T S T R E E T GARDEN GROVE, CALIFORNIA 92841 8 0 0 - 8 5 4 - 6 4 1 7...
-
Page 2: Table Of Contents
ABLE OF ONTENTS Model EST 1. SPECIFICATIONS ..................2 EST ..............................2 2. GETTING STARTED ..................3 2.1. EST ......................3 NTRODUCTION TO THE 2.2....................... 4 ECEIVING AND NSTALLATION 2.2.1. Electrical ..........................4 2.2.2. Plumbing ..........................5 2.2.3. Connecting the Scrap Accumulator and Drain ............... 5 3. -
Page 3: Specifications
65 PSIG, a pressure regulating valve must be installed in the water line to the dishmachine (by a qualified person). If flow pressure is lower than 30 PSIG, improper operation may result. Page MODEL EST INSTALLATION & OPERATION MANUAL Rev. 1.05C... -
Page 4: Getting Started
Its integrated scrap tray prevents food soil from entering the drain system. The EST can be run at a rate of 40 racks/160 covers per hour and its heavy-duty stainless steel construction assures long life and years of trouble free operation. -
Page 5: Receiving And Installation
Prior to installation make sure the electrical supply is compatible with the specifications on the machines data plate. The EST Dishmachine must be hard wired directly to a dedicated 115 VAC, 60Hz circuit equipped with proper circuit protection. The main power switch is at the top-right side of the control box. -
Page 6: Plumbing
The EST Dishmachine has a 2” drain. The following section explains how to connect the drain. Notice to Plumber: The plumber connecting this machine is responsible for making certain that... -
Page 7: Operation
Technical personnel are available during normal business hours at CMA Headquarters should you, as an installer, have any questions please call 800-854-6417. ∗ The chemicals and water level must be programmed by a qualified chemical specialist. Page MODEL EST INSTALLATION & OPERATION MANUAL Rev. 1.05C... -
Page 8: Startup Procedures
If the doors are lifted during a cycle, the machine will automatically stop running. The EST will run through the wash and rinse cycles automatically feeding the proper chemicals and then turn itself off. In an emergency you can turn off the machine by turning off the master switch located on the side of the control box. -
Page 9: Quick Service Guide
Reset or replace switch, P/N 00471.10 position Runs, but none of the other Faulty #2 Micro switch (cycle functions engage reset) Replace micro switch, P/N 411.00 Faulty ice cube relay (yellow relay) Replace relay, P/N 00636.00 Page MODEL EST INSTALLATION & OPERATION MANUAL Rev. 1.05C... -
Page 10: Addendum For Machines Installed In The City Of Chicago
1. All low energy models must have low-level sani alarms, both visual and audio. 2. All models must have a City of Chicago approval data label affixed to the machine. 3. Chlorine sanitizer must be a minimum of 100 PPM. Page MODEL EST INSTALLATION & OPERATION MANUAL Rev. 1.05C... -
Page 11: Electrical Diagram
Electrical Diagram 5. Electrical Diagram Page MODEL EST INSTALLATION & OPERATION MANUAL Rev. 1.05C...
