- Page 1 Network Appliance Platforms Hardware Platforms for Network Computing N2S-PCIE16X13A N2S-MBF301A N2S-MDM201A N2S-MFM101A Installation Guide Version: 1.1 Date of Release: 2024-09-04...
- Page 2 - assumed to be qualified in the servicing of computer equipment, such as professional system integrators, or service personnel and technicians. The latest version of this document can be found on Lanner’s official website, available either through the product page or through the Lanner Download Center page with a login account and password.
- Page 3 N2S-PCIE16X13A/MBF301A/MDM201A/MFM101A Installation Manual Contact Information Taiwan Corporate Headquarters China Lanner Electronics Inc. Beijing L&S Lancom Platform Tech. Co., Ltd. 7F, No.173, Sec.2, Datong Rd. Guodong LOFT 9 Layer No. 9 Huinan Road, Xizhi District, New Taipei City 22184, Huilongguan Town, Changping District, Beijing...
- Page 4 N2S-PCIE16X13A/MBF301A/MDM201A/MFM101A Installation Manual Safety Guidelines Follow these guidelines to ensure general safety: Keep the chassis area clear and dust-free during and after installation. Do not wear loose clothing or jewelry that could get caught in the chassis. Fasten your tie or scarf and roll up your sleeves.
-
Page 5: Table Of Contents
N2S-PCIE16X13A/MBF301A/MDM201A/MFM101A Installation Manual Table of Contents Chapter 1: Product Overview ............6 N2S-PCIE16X13A ........................... 6 N2S-MBF301A..........................7 N2S-MDM201A ..........................9 N2S-MFM101A ........................... 11 Chapter 2: Hardware Setup ............. 13 Opening the Cover ........................13 N2S-MBF301A: Installing DPU ....................14 N2S-MDM201A & N2S-MFM101A: Installing Adapter Card ............16 Appendix A: Terms and Conditions .......... -
Page 6: Chapter 1: Product Overview
The N2S-PCIE16X13A is a PCIe standard card carrier. It supports either one full-height, half-length (FHHL) or half-height, half-length (HHHL) PCIe Gen5 x16 card to fit in the Lanner appliance N2S NIC form factor. The N2S-MBF301, powered by the NVIDIA BlueField-3 DPU, along with the N2S-MDM201A/N2S- MFM101A, powered by the NVIDIA CX7 adapter, enable hardware offloads for software-defined networking, security, and management workloads. -
Page 7: N2S-Mbf301A
CPU. It features a PCIE Gen5, with a 2x 200G capacity, utilizing the Nvidia Bluefield-3 B3220 DPU card. This card is seamlessly integrated into the Lanner N2S front NIC module, catering to the needs of the Lanner system. - Page 8 N2S-PCIE16X13A/MBF301A/MDM201A/MFM101A Installation Manual Ethernet: 200GAUI-4 C2M, 200GBASE-CR4, 100GAUI-2 C2M, 100GBASE-CR4, 100GBASE-CR2, 100GBASE-CR1, 50GAUI-2 C2M, Ethernet 50GAUI-1 C2M, 50GBASE-CR, 50GBASE-R2, 40GBASE-CR4, 40GBASE-R2, 25GBASE-R, 10GBASE-R, 10GBASE-CX4, 1000BASE- CX, CAUI-4 C2M, 25GAUI C2M, XLAUI C2M , XLPPI, SFI System Compatibility NCA-6530, NCA-6250, NCA-6040, NCA-5540, NCA-5330*...
-
Page 9: N2S-Mdm201A
N2S-PCIE16X13A/MBF301A/MDM201A/MFM101A Installation Manual N2S-MDM201A The N2S-MDM201A is a Lanner N2S form factor front NIC module designed to accommodate Nvidia ConnectX-7 200G Adapter Cards. Ordering Information SKU No. Main Features N2S-MDM201A Lanner N2S Standard NIC Module with Nvidia CX7 Adapter Card, 2x 200GbE QSFP112... - Page 10 N2S-PCIE16X13A/MBF301A/MDM201A/MFM101A Installation Manual interfaces To IO card 1x PCIe Gen5 x 16 connector Voltage 12V, 3.3VAUX Power Consumption 24.9W Environmental 0~40ºC Operating Temperature Parameters -40~70ºC Non-Operating 10~85% Operating Humidity (RH) 10~90% Non-Operating Size (WxDxH) 77.2 x 125 x 39mm System...
-
Page 11: N2S-Mfm101A
N2S-PCIE16X13A/MBF301A/MDM201A/MFM101A Installation Manual N2S-MFM101A The N2S-MFM101A is a Lanner N2S form factor front NIC module designed to accommodate Nvidia ConnectX-7 400G Adapter Cards. Ordering Information SKU No. Main Features N2S-MFM101A Lanner N2S Standard NIC Module with Nvidia CX7 Adapter Card, 1x 400GbE QSFP RHS... - Page 12 N2S-PCIE16X13A/MBF301A/MDM201A/MFM101A Installation Manual requirement Differential Impedance 85+/-10% ohm 1.6mm thickness Plating connector and golden finger Au 15u" min. To Host system 2x PCIe Gen5 x 8 golden finger Riser Cable interfaces To IO card 1x PCIe Gen5 x 16 connector Voltage 12V, 3.3VAUX...
-
Page 13: Chapter 2: Hardware Setup
N2S-PCIE16X13A/MBF301A/MDM201A/MFM101A Installation Manual CHAPTER 2: HARDWARE SETUP To reduce the risk of personal injury, electric shock, or damage to the system, please remove all power connections and wear ESD protection gloves when handling the installation steps. Opening the Cover 1. Unscrew the four (4) screws on the cover. -
Page 14: N2S-Mbf301A: Installing Dpu
N2S-PCIE16X13A/MBF301A/MDM201A/MFM101A Installation Manual N2S-MBF301A: Installing DPU The Module Kit includes the following items: 1x PCIe Standard Card Carrier 1x Nvidia Bluefield3 DPU 1x DPU Holder 1x DPU Clip N2S-PCIE16X13A Carrier Clip Holder Bluefield3 DPU 1. Open the cover and unscrew the front panel. - Page 15 N2S-PCIE16X13A/MBF301A/MDM201A/MFM101A Installation Manual 2. Inert the DPU module into the socket until it is fully seated. 3. Encase with the front panel and clip, secure with five (5) screws, and two (2) screws on the bottom side. Bottom Side 4. Place the holder and secure with one screw on the bottom side.
-
Page 16: N2S-Mdm201A & N2S-Mfm101A: Installing Adapter Card
N2S-PCIE16X13A/MBF301A/MDM201A/MFM101A Installation Manual N2S-MDM201A & N2S-MFM101A: Installing Adapter Card The Module Kit includes the following items: 1x PCIe Standard Card Carrier 1x Nvidia CX7 Adapter Card 1x Holder 1x Clip N2S-PCIE16X13A Carrier Clip Holder CX7 OSFP Adapter Card 1. Open the cover and unscrew the front panel. - Page 17 N2S-PCIE16X13A/MBF301A/MDM201A/MFM101A Installation Manual 2. Inert the adapter card module into the socket until it is fully seated. 3. Encase with the front panel, secure with three (3) screws, and two (2) screws on the bottom side. Bottom Side 4. Then place in the clip and secure with two...
- Page 18 N2S-PCIE16X13A/MBF301A/MDM201A/MFM101A Installation Manual 4. Place the holder and secure with one screw on the bottom side. Watch out for the two latch buttons. Bottom Side 5. Place the cover back on and secure with the original screws.
-
Page 19: Appendix A: Terms And Conditions
N2S-PCIE16X13A/MBF301A/MDM201A/MFM101A Installation Manual APPENDIX A: TERMS AND CONDITIONS Warranty Policy 1. All products are under warranty against defects in materials and workmanship for a period of one year from the date of purchase. 2. The buyer will bear the return freight charges for goods returned for repair within the warranty period;... - Page 20 N2S-PCIE16X13A/MBF301A/MDM201A/MFM101A Installation Manual RMA Service Request Form When requesting RMA service, please fill out the following form. Without this form enclosed, your RMA cannot be processed.
