Main Components - Integra Integralift 230 User Manual

Integralift consists of a vertical cabinet and a top cabinet where the lift is integrated. The
lifting bar and remote control have dedicated places in the vertical cabinet. The person being
lifted is hereby called the User and the one giving assistance is called Assistant.
5
8
7
1. Vertical cabinet
2. Top cabinet
3. Vertical structure
4. Back jib
Integralift 230 User manual rev 2.6

3. Main components

3
4
6
9
10
Lifter activated
5. Front jib
6. Battery charger: 24V
MASCOT 9940
7. Lift strap
2
11
Lifter inside cabinet
8. Lifting bar
9. Remote control
10. Emergency stop
11. Sling
1
5
