Elo TouchSystems 04LS Quick Installation Manual

75x75mm VESA Adapter
Menu button
Power button
OSD and Power Locked:
1.Press the "Menu Key" for 5s to enable / disable
the OSD Locking feature.
2.Press the "Menu Key" and the button "Power"
for 3s simultaneously to enable / disable the
Power Locking feature.
Elo Technical Support
Online self-help:www.elotouch.com/support
America
800-ELO-TOUCH
Tel +1 408 597 8000
EloSales.NA@elotouch.com
Europe (EMEA)
Tel +32 (0)16 930 136
EMEA.Sales@elotouch.com
The information in this document is subject to change without notice. Elo Touch Solutions, Inc.
and its Affiliates (collectively "Elo") makes no representations or warranties with respect to
the contents herein, and specifically disclaims any implied warranties of merchantability
or fitness for a particular purpose. Elo reserves the right to revise this publication and to make
changes from time to time in the content hereof without obligation of Elo to notify any person
of such revisions or changes.
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language or computer language, in any form or by any means,
including, but not limited to, electronic, magnetic, optical, chemical, manual, or otherwise
without prior written permission of Elo Touch Solutions, Inc.
Elo and the Elo logo are either trademarks or registered trademarks of Elo Touch Solutions, Inc.
© 2024 Elo Touch Solutions, Inc. All rights reserved.
USB-C connection
Asia-Pacific
Tel +86 (21) 3329 1385
EloAsia@elotouch.com
Q u ick Installation Guide
04LS Touchmonitors
www.elotouch.com
Revision A
P/N E878596
E8 7 8 5 9 6
