Elo TouchSystems EloPOS Z30 Quick Installation Manual

Contents
EloPOS Z30 (1)
150W DC Power Adapter and cables
M3x5mm I/O cover security screw (1)
Stand Mounting bracket and screw (1)
Tie-wraps (2)
I/O Connections
USB-C (E483135 Only)
DC Power In
Cash Drawer
Powered USB
USB-A
USB-A
Ethernet
Elo Technical Support
Online self-help: www.elotouch.com/support
America Europe (EMEA)
800-ELO-TOUCH Tel +32 16 930 136
Tel +1 408 597 8000 emea.sales@elotouch.com
elosales.na@elotouch.com
