Dacor ED30 Planning Manual

Revised
01/08/08
1 1/8"
(29mm)
ED Door Panel
Height
29 5/8" (752mm)
ID Door Panel
Height
26 7/8" (683mm)
SIDE VIEW - Door oPEN
ED or ID30 – 29 7/8" (759mm)
Cycle ON indicating lights
FroNt VIEW
Model No.
ED30
15 A, 120 Vac, 60 Hz dedicated, grounded, three
prong power outlet. See model number label on
product for total connected loaded.
ID30
Web: http://www.Dacor.com
Corporate Phone: 800-793-0093
ED30, ID30
30" Wide Dishwashers
23 3/4" (603mm)
Power Requirements
1 5/8"
Adjustable
(41mm)
Toe-kick
Front Plate
47" (1194mm)*
* Allows for drain hose on back of unit
SIDE VIEW - Door oPEN
Anti-tip anchor into material under
countertop or adjacent cabinets
90˚
24" Min.
(610mm)
Utilities Access Hole
ED or ID30 – 30" Min. (762mm)
CUt-oUt FroNt VIEW
Water
Pressure
20 to 120 psi
120°F, minimum
(138 - 827 kPa)
Specifications are subject to change without notice.
See installation instructions for additional details.
PLANNING
GUIDE
1/2
19 1/4" (489mm) to
20 1/4" (514mm)*
90˚
34"
(864mm)
to
36 1/4"
5"
(921mm)
(127mm)
8"
(203mm)
Water Approximate
Temperature Shipping Weight
215 lbs.
218 lbs.
36 1/4"
(921mm)
to
34"
(864mm)
10.1
