- Page 1 Order code: EQLED45 Order code: EQLED45 user manual user manual w w w . p r o l i g h t . c o . u k...
-
Page 2: Safety Instructions
Equinox Dualize Safety WARNING FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOUR INITIAL START-UP! CAUTION! Keep this equipment away from rain, moisture and liquids. SAFETY INSTRUCTIONS Every person involved with the installation, operation & maintenance of this equipment should: Be competent Follow the instructions of this manual... -
Page 3: Operating Determinations
Equinox Dualize Safety IMPORTANT: The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual or any unauthorised modification to the equipment. • Never let the power-cable come into contact with other cables. Handle the power-cable and all mains voltage connections with particular caution! •... - Page 4 Equinox Dualize Technical specifications You should find inside the Equinox carton the following items: 1, Equinox Dualize 2, Power cable 3, Instruction manual Technical Specifications: DMX channels: 6 Voltage: AC 240V - 50Hz 128 Ultra Bright LED’s (R: 64, G: 40, B:24) Fuse: 1 Amp Power Consumption: 61W Dimensions: 220 x 155 x 389mm...
- Page 5 Equinox Dualizes Overview Overview DMX Function Chart Channel Value Function Auto clockwise right mirror rotation Individual control of right mirror (0-360˚) 2-199 Auto anti-clockwise right mirror rotation 200-255 Auto clockwise left mirror rotation Individual control of left mirror (0-360˚) 2-199 Auto anti-clockwise left mirror rotation 200-255 Mirror rotation speed (0=fast, 255=slow)
- Page 6 Equinox Dualize DMX Set up DMX-512: • DMX (Digital Multiplex) is a universal protocol used as a form of communication between intelligent fixtures and controllers. A DMX controller sends DMX data instructions form the controller to the fixture. DMX data is sent as serial data that travels from fixture to fixture via the DATA “IN”...
- Page 7 Equinox Dualize DMX Set up Notice: • Be sure to follow figures 2 & 3 when making your own cables. Do not connect the cable’s shield conductor to the ground lug or allow the shield conductor to come in contact with the XLR’s outer casing.
- Page 8 Equinox Dualize Dip Switch Reference Chart DMX Dip Switch Quick Reference Chart Dip Switch Position Dip Switch position DMX Address...
