Icom IC-F4029TDR Service Manual Addendum page 36

• CONNECTION
Standard signal generator
0.1 µV to 32 mV
(–127 dBm to –17 dBm)
CAUTION!
DO NOT transmit while
the SSG is connected to
the antenna connector
ADAPTER
Order No.: 6510023350
JIG Name: MM8430-2600RA1
to the J701 (PA-C UNIT)
+ –
DC power supply
7.2 V /1 A
• JIG CABLES
[JIG cable 1]
(GND )
JIG cable
2-conductor 2.5 (d) mm plug
(MIC)
[JIG cable 2]
(SP)
3-conductor 3.5(d) mm plug
AC
millivoltmeter
Audio
generator
To [MIC] jack
JIG cable 1
To [SP] jack
IC-F4029SDR/TDR
PTT
33 k
(to the audio generator " + " )
(SP + )
(GND)
(CLONE)
5 - 2
Attenuator
10 dB or 20 dB deviation meter
RF power meter
0.01–1 W/50
Frequency
counter
OPC-478 (RS-232C type)
OPC-478U/UC (USB type)
+
JIG cable 2
)
"
)
OPC-478/U
FM
Osciiloscope
to RS-232C port
to USB port
PC
SINAD meter
Speaker (8 )
