Icom IC-F4029TDR Service Manual Addendum page 2

Feb. 2012
SECTION 6.
[VERSION LIST]
Model Version
EUR-02
IC-F4029SDR
UK-02
EUR-02
IC-F4029TDR
UK-02
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
PARTS LIST
Symbol
[B]
[D]
[A]
[C]
[MAIN-C UNIT]
REF PARTS
NO. NO.
IC2 1140005991 S.IC MB15A02PFV1-G-BND-ERE1
IC3 1130011770 S.IC CD4066BPWR
IC5 1110005320 S.IC NJM13403V-TE1-#ZZZB
IC6 1110005340 S.IC NJM12902V-TE1-#ZZZB
IC7 1110005340 S.IC NJM12902V-TE1-#ZZZB
IC8 1110006260 S.IC BD5242G-TR
IC9 1110003201 S.IC TA31136FNG(EL)
IC10 1130015560 S.IC S-24C64CI-T8T1U3
IC12 1190001350 S.IC M62364FP 600D
IC15 1110001811 S.IC TA7368FG(5ER)
IC17 1110005350 S.IC NJM2870F05-TE1-#FZZB
IC20 1130016390 S.IC PT6586-LQ <HST>
IC22 1140011511 S.IC HD64F2238BTF13V(EMPTY)
IC23 1190001340 S.IC M62334FP 600C
IC24 1110005310 S.IC AN6123MS
IC25 1130009981 S.IC TC7W53FK(TE85LF)
Q4 1560000841 S.FET 2SK1829(TE85RF)
Q5 1580000731 S.FET 3SK293(TE85LF)
Q6 1580000800 S.FET 3SK324UG-TL-E
Q7 1530002601 S.TRA 2SC4215-O(TE85RF)
Q8 1530002601 S.TRA 2SC4215-O(TE85RF)
Q9 1590001330 S.TRA DTA114EUA T106
Eqv. 1590004010 S.TRA KRA302-RTK/P
Eqv. 1590004740 S.TRA LMUN5111T1G <SLVJ>
Q14 1530004110 S.TRA MT3S37T(TE85LF)
Q15 1530003260 S.TRA 2SC5006-T1
Q16 1530002921 S.TRA 2SC4226-T1 Y25 (R25)
Q17 1530002921 S.TRA 2SC4226-T1 Y25 (R25)
Q18 1590001400 S.TRA XP1214(TX)
Q19 1590003291 S.TRA UNR9213G0L
Q20 1530002851 S.TRA 2SC4116-BL(TE85RF)
Q21 1560000541 S.FET 2SK880-Y(T5RICOMF)
Q22 1530003260 S.TRA 2SC5006-T1
Q23 1510001110 S.TRA 2SA1577T106R
Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14
Q24 1510001110 S.TRA 2SA1577T106R
Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14
Q25 1510001110 S.TRA 2SA1577T106R
Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14
Q26 1520000460 S.TRA 2SB1132 T100 R
Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ>
Q27 1590001190 S.TRA XP6501-(TX).AB
Q28 1590003291 S.TRA UNR9213G0L
Q29 1530004110 S.TRA MT3S37T(TE85LF)
Q30 1590003291 S.TRA UNR9213G0L
1590003291 S.TRA UNR9213G0L
1590003291 S.TRA UNR9213G0L
Q31 1560001360 S.FET 2SK3019 TL
Eqv. 1560001840 S.FET 2SK3107-T1-AT
Eqv. 1560001860 S.FET 2SK1824-T1-A
Q32 1560001360 S.FET 2SK3019 TL
Eqv. 1560001840 S.FET 2SK3107-T1-AT
Eqv. 1560001860 S.FET 2SK1824-T1-A
Q33 1590003291 S.TRA UNR9213G0L
Q34 1560001360 S.FET 2SK3019 TL
Eqv. 1560001840 S.FET 2SK3107-T1-AT
Eqv. 1560001860 S.FET 2SK1824-T1-A
Q35 1590003291 S.TRA UNR9213G0L
Q36 1560001360 S.FET 2SK3019 TL
Eqv. 1560001840 S.FET 2SK3107-T1-AT
Eqv. 1560001860 S.FET 2SK1824-T1-A
Q37 1590003291 S.TRA UNR9213G0L
Q39 1590001650 S.TRA XP4601(TX)
Q40 1590003291 S.TRA UNR9213G0L
Q41 1590001190 S.TRA XP6501-(TX).AB
Q42 1520000460 S.TRA 2SB1132 T100 R
Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ>
Q43 1590003381 S.TRA UNR9111G0L
Q44 1590003271 S.TRA UNR9210G0L
Q45 1590003231 S.TRA UNR9113G0L
Q46 1590003291 S.TRA UNR9213G0L
D2 1750000520 S.DIO DAN222TL
D3 1750000520 S.DIO DAN222TL
D4 1790001251 S.DIO MA2S1110GL
D6 1790001261 S.DIO MA2S077G0L
D8 1790001251 S.DIO MA2S1110GL
D9 1750000711 S.VAR HVC350BTRF-E
D10 1750000711 S.VAR HVC350BTRF-E
D11 1750000711 S.VAR HVC350BTRF-E
D12 1720000570 S.VAR MA368(TX)
D13 1750000711 S.VAR HVC350BTRF-E
D14 1750000711 S.VAR HVC350BTRF-E
D15 1750000711 S.VAR HVC350BTRF-E
D16 1750000581 S.DIO 1SV307(TPH3F)
D17 1790001261 S.DIO MA2S077G0L
D18 1790001251 S.DIO MA2S1110GL
D19 1750000711 S.VAR HVC350BTRF-E
D21 1750000520 S.DIO DAN222TL
D23 1790001251 S.DIO MA2S1110GL
D25 1750000711 S.VAR HVC350BTRF-E
D28 1790001670 S.DIO RB706F-40T106
FI1 2030000150 S.MON DSF753SB 46.350 MHz (FL-335)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
1
DESCRIPTION M.
LOCATION
T 81.2/34.5
B 40.4/22.0
B 40.4/12.8
B 55.4/28.7
B 40.4/40.8
B 21.3/42.0
T 81.6/17.0
B
B 40.4/30.6
T 98.9/18.3
B 95.2/16.5
T 57.3/20.3
B 16.4/24.5
T 99.9/42.5
B 30.0/12.4
B
T 90.3/32.7
B 91.0/33.2
B 88.6/22.4
T 88.2/12.5
T 76.0/11.5
B 60.2/20.4
B 79.9/31.3
B 73.1/29.9
B 75.7/25.5
B 74.8/32.3
T 72.9/31.7
T 73.1/29.3
B 97.3/25.9
T 76.3/26.2
T 80.7/24.0
B
B 50.4/19.3
B 85.7/12.3
B 101.6/17.9
B 101.7/22.7
B 99.3/21.9
B 78.2/25.1
[A] B 99.3/24.3
[B]
[C]
B
B
B
B 46.6/12.8
B 46.6/15.2
B
B
B 55.2/10.4
B 39.7/37.0
T 96.4/24.6
T 100.4/24.4
T
B 28.3/20.0
T
T 99.0/32.9
T 69.3/16.8
T 72.2/16.8
T 84.0/28.9
B 27.7/29.2
B 97.1/22.9
B 68.6/29.3
B 70.1/27.6
B 68.3/31.8
B 68.5/26.4
B 71.4/25.6
B 85.3/28.4
B 85.3/31.4
B 88.6/14.3
B 87.8/17.5
T 92.4/32.7
B 97.1/36.1
B 31.9/21.3
B 31.9/23.0
B 99.8/35.9
B 28.0/17.7
T 89.9/19.9
S.=Surface mount
H/V
4.4/37.1
28.4/4.8
51.0/6.3
41.9/6.8
37.7/6.8
35.1/6.8
37.7/4.6
40.0/4.6
78.4/7.2
53.9/4.8
