GENUINE LOGO WELCOME LIGHT
INSTALLATION INSTRUCTIONS
Thank you for purchasing a Genuine Mazda Accessory.
Before installation, please thoroughly read these instructions.
For your safety, please read the contents of this booklet to properly install and care for the Logo
Welcome Light. Keep these instructions with your vehicle records for future reference.
There are several ( ! WARNING) and ( ! CAUTION) sections in this booklet concerning safety
when installing the Logo Welcome Light. Always read and follow them in order to prevent
injuries, accidents, and possible damage to the vehicle.
WARNING Indicates a situation in which serious injury or death could result if the warning is
ignored.
CAUTION Indicates a situation in which bodily injury or damage to the vehicle could result if
the caution is ignored.
• Do not modify the Logo Welcome Light.
• Do not install the Logo Welcome Light in any way other than described in the following
instructions.
• If in any doubt, please ask your Mazda dealer to install the accessory in order to prevent errors
in installation.
• If you have any questions about the use of the accessory, ask your Mazda dealer for proper
advice before using it.
• Mazda and its suppliers are not responsible for injuries, accidents, and damage to persons and
property that arise from the failure of the dealer or installer to follow these instructions.
• To ensure safety and reliability of the work, installation, removal and disposal work must be
carried out by an Authorized Mazda Dealership.
Page: 1/20
WARNING
PART NAME
PART NUMBER
Logo Welcome Light
KMV6-V4-590
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mazda KMV6-V4-590
Summary of Contents for Mazda KMV6-V4-590
- Page 1 • Do not install the Logo Welcome Light in any way other than described in the following instructions. • If in any doubt, please ask your Mazda dealer to install the accessory in order to prevent errors in installation. • If you have any questions about the use of the accessory, ask your Mazda dealer for proper advice before using it.
- Page 2 1. PARTS Verify that this kit includes all the following parts and that the parts are not damaged. KR9P V4-595 Page: 2/20...
-
Page 3: Installation View
2. INSTALLATION VIEW Page: 3/20... -
Page 4: Before Installation
3. BEFORE INSTALLATION REQUIRED TOOLS Nylon trim remover Flathead screwdriver Power Drill Trim clip remover / tack puller Ratchet Deburring Tool Philips screwdriver 10mm socket Center Punch Small scale ruler Pliers Small utility knife OTHER PREPERATIONS Eye protection IPA (Isopropyl alcohol) To perform the installation work safely and maintain functionality and quality, thoroughly read these instructions before performing the procedures and always heed the warnings and precautions. - Page 5 4. PREPERATION DOOR TRIM REMOVAL Door Trim Protection A x protective tape to the positions shown in the figures. Tape must be applied as shown prior to the removal of any door trim parts. Tape can be removed at the end of the installation after the door trim has been completely reassembled.
- Page 6 5. DOOR TRIM REMOVAL Remove Cover Assembly (Right Side) Remove using the procedure shown in the figure. Step Part name Applicable condition Cover assembly All models (See Cover assembly removal note.) Cover assembly removal note Remove the cover assembly as shown in the figure. Symbol Content 2 ...
- Page 7 Disconnect Negative Lead-Acid Battery Terminal Warning Contact with the positive lead-acid battery terminal could cause electrocution due to a short circuit and result in serious injury or death, or damage to vehicle parts. Do not contact the positive lead-acid battery terminal when performing the procedure.
- Page 8 Disconnect Negative Lead-Acid Battery Terminal Instructions for Driver side are the same for Passenger side Remove Driver Side Inner Garnish Remove using the procedure shown in the figure. The figure shows the left side (same as right side). Step Part name Applicable condition Inner garnish All models...
- Page 9 Power window main switch component removal note Remove the power window main switch component as shown in the figure. Disconnect the cable. Symbol Content Protective tape attachment positions Remove Driver Side Front Door Speaker Grille Remove using the procedure shown in the figure. The figure shows the left side (same as right side).
- Page 10 Inner handle and cover removal note Remove the inner handle cover as shown in the figure. The figure shows the left side (same as right side). Remove Driver Side Front Door Trim Remove using the procedure shown in the figure. The figure shows the left side (same as right side).
- Page 11 Front door trim removal note Remove the front door trim as shown in the figure. The figure shows the left side (same as right side). Disconnect the electrical cables. Remove the remaining clips from the car and attach them to the front door trim. The figure shows the left side (same as right side).
- Page 12 6. DOOR HARNESS INSTALLATION DRIVER SIDE SHOWN (PASSENGER SIDE IS SYMMETRIC) DOOR HARNESS INSTALLATION Unclip the connector and bring it out for easy access. Carefully cut back the felt wrap to expose a total of about 1-1.5 inches of the wires. WARNING MAKE SURE NOT TO DAMAGE VEHICLE HARNESS Install Electro Taps on the exposed wires according to...
-
Page 13: Connector Diagram
ELECTRO TAP PROCEDURE Vehicle wiring harness Insert the vehicle wiring harness into the electro tap Fold the electro tap as shown in the figure and lock it. CAUTION Electro tap Firmly engage the lock part until a click sound is heard. Vehicle wiring harness Lock Insert the harness to the end of the electro tap. - Page 14 70 mm 30 mm Cut 2 pieces of foam tape and use one of the 70mm portions to wrap connectors. Secure the fuse holder to the vehicle harness by wrapping them with the other 70mm piece of foam tape. Return the vehicle harness through its original routing and plug the connector back into the ECU Page: 14/20...
- Page 15 7. LED HOUSING INSTALLATION HOLE SAW INCLUDED IN KIT DOOR TRIM – DRILLING THE HOLE Measure to the dimensions shown. Using a hole punch, mark the drill location. Use the included 19mm hole saw to drill the hole in the bottom of the trim panel. Deburr to ensure a clean hole.
- Page 16 DOOR TRIM – INSTALLING THE LIGHT Remove the thumb screw from the light housing and harness. Turn the trim panel over. Route the harness and light housing up through the hole. Finger tighten the thumb screw to hold the light in place.
- Page 17 Wrap the harness as shown and cover with foam tape. Use a cable tie to secure the wrapped harness to the cable tie holder. 8. REASSEMBLY REATTACH THE DOOR TRIM Bring the door trim panel to the door and reattach the electrical connectors and components in the reverse order of disassembly.
- Page 18 Set the top row of clip fasteners only. Make sure a slight gap can be made at the bottom to access the Logo Welcome Light clip. Reconnect the negative terminal on the 12V battery and check that the Logo Welcome Light illuminates with the courtesy circuit.
- Page 19 Tighten down the thumb screw and then torque the locking screw to secure the light in position. Recheck the logo light so that the image is in-line with the door. 0.5 Nm (4.4 IN LBS) 2.5 mm Hex Key Look for the Logo Welcome Light connector. Use the last 30mm piece of foam tape to wrap the Logo Welcome Light connector.
- Page 20 10. INSPECTION Inspection Items (O) Inspection Parts Scratches / Dirt / Installation / Clearance / Fit Harness Tighttening / Operaion Check Interference Engagement Negative battery terminal and Cover Logo Welcome Lights Function Logo Welcome Lights Image Orientation is correct Logo Welcome Lights is secured in place.
