3.3.2. Change unit
You can choose from the following units:
•
Force gauge: N, KN, kg, lb, oz, g and daN.
•
Torque meter: Nm, mNm, kg.cm, lbin, lbft, ozin.
Some units may not be available, depending on the load cell capacity. For example, for a 150Nm
capacity load cell, it is not possible to measure in mNm.
To change the uni, press the U key. Each successive press will select the next unit until you return to
the starting unit. The Centor Wireless II will automatically convert the display and capacity to the
new chosen unit and display the corresponding unit symbol.
The number of decimal places displayed changes according to the unit selected. It corresponds to
1/10,000 of the sensor capacity.

3.3.3. Change display order

The torque meter detects and stores the maximum tension and compression values. Press the
key. The display order of the various values will shift upwards. The top line will then move to the
bottom. Each time you press this key, the display changes. Centor Wireless II remembers the display
order when it is switched off.

3.3.4. Auto-off

Automatic shutdown saves battery charge. The force gauge is automatically switched off after 15
minutes without pressing any key. This value can be changed in the menu DISPLAY.
3.3.5. Memory
A long press on this key activates or deactivates the peak save feature. When this
feature is activated, the save counter is displayed at the bottom right of the screen. Up
to 500 values can be saved.
A short press on this key saves the peak in memory, which has a blue arrow in front of
it. Each press increments the save counter at the bottom of the screen. Access to the values and setting
of the saved value is via the menu.
