nvent 4Z34 Instruction Sheet page 2

INSTRUCTION SHEET
Global Part Local Part
Number Number
4Z34 170650
6Z34 170720
**8Z34 N/A
*6Z34 installed on 3/8" [M10] smooth rod in the F2 direction has a Static Load Rating of 15 lb [67 N]
**8Z34 to be installed on 1/2" [M12] and 5/8"[M16] threaded rod sizes only.
1. Squeeze Fastener 2. Connect top edge
over rod/wire
Fastener connected
to back of box
nVent, nVent CADDY, nVent ERICO Cadweld, nVent ERICO Critec, nVent ERICO, nVent ERIFLEX, and nVent LENTON are
owned by nVent or its global affiliates. All other trademarks are the property of their respective owners. nVent reserves the
right to change specifications without prior notice.
TECHNICAL SUPPORT:
www.nVent.com
Rod Size (RS)
(in [mm])
1/4" [M4 - M6]
3/8" [M10]
1/2" [M12] - 5/8" [M16]
3. Twist into place
and release
Flange
25 lb [111 N]
Ultimate Static Load Limit
(Not for 8Z4S or 8Z34)
CFS116_N 2 OF 2
Flange Thickness (FT)
Wire Size (RS)
(in [mm])
#12 - #8 1/8" [3] - 3/8" [9]
N/A 3/8" [9] - 7/16" [11]
N/A
Secure Electricl Box to 4Z4S or 6Z4S
with Nut (Not for 8Z4S or 8Z34)
20 lb [90 N]
Static Load Limit
© 1998-2021 nVent All Rights Reserved
Static Load Rating (lb [N])
F1
25 [111]
25 [111]
N/A N/A
Flange
Secure Electricl Box to
4Z4S or 6Z4S with Nut
(Not for 8Z4S or 8Z34)
For position only
F2
20 [90]
*20 [90]
50 [222]
15 lb [67 N]
Ultimate Static
Load Limit
