nvent 4Z34 Instruction Sheet

INSTRUCTION SHEET

4Z34
6Z34
Part Article Fig.
Number Number No
4Z34 170650 1
4Z346M 171050
4Z34812M 171060 2
4Z3416M N/A
4Z348P N/A
4Z3412P N/A 3
4Z3416P N/A
4Z34CTS 172950 6
4Z4S N/A 4
6Z34 170720 1
6Z346M 171080
2
6Z34812M 171090
6Z3416M N/A
6Z348P N/A
6Z3412P N/A 3
6Z3416P N/A
6Z34CTS 172960 6
6Z4S N/A 4
6Z34J2 N/A 5
8Z34 N/A 1
8Z34812M N/A 2
8Z4S N/A 4
Note: May require dedicated drop wire/rod. Consult local code authority.
WARNING:
1. nVent products shall be installed and used only as indicated in nVent product instruction sheets and training materials. Instruction sheets are available at
www.nVent.com and from your nVent customer service representative.
2. nVent products must never be used for a purpose other than the purpose for which they were designed or in a manner that exceeds specified load ratings.
3. All instructions must be completely followed to ensure proper and safe installation and performance.
4. Improper installation, misuse, misapplication or other failure to completely follow nVent's instructions and warnings may cause product malfunction, property
damage, serious bodily injury and/or death, and void your warranty.
5. Products that are manufactured using spring steel components shall be used only in a non-corrosive indoor environment.
6. All pipe supports, hangers, intermediate components and structural attachments must ONLY be used as described herein and are NEVER to be used for any
other purpose.
NOTE: All load ratings are for static conditions and do not account for dynamic loading such as wind, water or seismic loads, unless otherwise noted.
The customer is responsible for:
a. Conformance to all governing codes.
b. The integrity of structures to which the products are attached, including their capability of safely accepting the loads imposed, as evaluated by a qualified
engineer.
c. Using appropriate industry standard hardware as noted above.
SAFETY INSTRUCTIONS:
All governing codes and regulations and those required by the job site must be observed.
Always use appropriate safety equipment such as eye protection, hard hat, and gloves as appropriate to the application.
nVent, nVent CADDY, nVent ERICO Cadweld, nVent ERICO Critec, nVent ERICO, nVent ERIFLEX, and nVent LENTON are
owned by nVent or its global affiliates. All other trademarks are the property of their respective owners. nVent reserves the
right to change specifications without prior notice.
TECHNICAL SUPPORT:
www.nVent.com
4Z4S 8Z34
6Z4S 8Z4S
#12 Wire thru 1/4" [6] plain or threaded rod
14-2 thru 12-3 MC/AC cable; #12 Wire thru 1/4" [6] plain or threaded rod
1/2" [13] - 3/4" [19] Conduit; #12 Wire thru 1/4" [6] plain or threaded rod
3/4" [19] - 1" [25] Conduit; #12 Wire thru 1/4" [6] plain or threaded rod
1/2" [13] EMT Conduit; #12 Wire thru 1/4" [6] plain or threaded rod
3/4" [19] EMT Conduit; #12 Wire thru 1/4" [6] plain or threaded rod
1" [25] EMT Conduit; #12 Wire thru 1/4" [6] plain or threaded rod
Cable tray to rod clip, M4, M6, M8 rod
With stud, #12 Wire thru 1/4" [6] plain or threaded rod
3/8" [10] plain or threaded rod
14-2 thru 12-3 MC/AC cable; 3/8" [10] plain or threaded rod
1/2" [13] or 3/4" [19] Conduit; 3/8" [10] Plain or threaded rod
3/4" [19] - 1" [25] Conduit; 3/8" [10] plain or threaded rod
1/2" [13] EMT conduit; 3/8" [10] plain or threaded rod
3/4" [19] EMT conduit; 3/8" [10] plain or threaded rod
1" [25] EMT conduit; 3/8" [10 plain or threaded rod
Cable tray to rod clip, M8, M10, M12 rod
With stud; 3/8" [10] plain or threaded rod
3/8" plain or threaded rod, C purlin hammer-on
1/2" [13] or 5/8" [16] threaded rod
1/2" [13] or 3/4" [19] Conduit; 1/2" [13] or 5/8" [16] threaded rod
With stud, 1/2" [13] or 5/8" [16] threaded rod
CFS116_N
FIG. 1 FIG. 2
Description
1 OF 2
© 1998-2021 nVent All Rights Reserved
FIG. 3 FIG. 4 FIG. 5
Flange Size
1/8" [3] - 3/8" [9]
3/8" [9] - 7/16" [11]
FIG. 6
N/A
N/A
N/A
