MUV7-50DR12/5 or 16/5 &
MUV7-50PS-12 or 16 & MUV7-50PS-OU
MultiVoltage Oxidizing UVC System
Installation & Maintenance Instructions
UNPACKING THE UNIT
The optional oxidizing unit is shipped with the 5" lamp installed.
The germicidal lamp is placed in a box with protective packaging.
When handling lamps take care to not touch the glass portion of
the lamp with bare hands. Oils from the hands can cause "hot
spots" which reduce lamp life. Handle by the end caps or use
a soft cloth. If you accidentally touch a lamp, clean it using the
included alcohol cleaning pad or a soft cloth dampened with rub-
bing alcohol. The lamp is fragile and proper care must be taken
when removing from packaging.
Depending on your configuration,
the following parts may be included:
• Power Supply
• Optional Oxidizing Unit
• Germicidal Twin H Lamp (packed in lamp box)
• Twelve (12) Sheet Metal Screws
IMPORTANT: SAFETY INSTRUCTIONS
When installing and using this electrical equipment, basic safety precautions
1. READ AND FOLLOW ALL INSTRUCTIONS.
2. Always be sure the unit is unplugged during installation or service procedures.
3.
The ultraviolet light produced by the UV lamp is harmful to your eyes. Do not look directly at
the lamp. Should it become necessary to view the lamp, use UV-protected goggles.
Lors de l'installation et de l'utilisation de cet équipement, des précautions devront être suivies.
1- Lire et suivre les étapes attentivement.
2- Assurez vous de toujours débrancher avant l installation ou le service.
3-
Ne pas regarder la lampe directement avec les yeux. Si nécessaire de le faire,
veuillez porter les lunettes de soleil contre les rayons U.V.
Important: Instructions de securité
should always be followed including the following:
3099107
• Four (4) caution labels
• Strain relief connector
• Alcohol pad for cleaning lamps
• Installation & maintenance instructions
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PremierOne MUV7-50DR16/5
Summary of Contents for PremierOne MUV7-50DR16/5
- Page 1 MUV7-50DR12/5 or 16/5 & MUV7-50PS-12 or 16 & MUV7-50PS-OU MultiVoltage Oxidizing UVC System Installation & Maintenance Instructions UNPACKING THE UNIT The optional oxidizing unit is shipped with the 5” lamp installed. The germicidal lamp is placed in a box with protective packaging. When handling lamps take care to not touch the glass portion of 3099107 the lamp with bare hands.
-
Page 2: Installation
INSTALLATION: If there is a device that creates ozone in the space such as an ionizing air cleaner, it is recommended the oxidizing unit not be used in this application. Use one of our germicidal only models instead. Homes with multiple air handlers: install this unit on the main level air handler and a germicidal only model on the other air handler(s). - Page 3 WIRING/FUSE It is recommended you interlock with the system blower or install a blower door safety switch so the unit powers off when the system is serviced. With the oxidizing unit installed, the unit must cycle with the The multi-voltage ballast is self-adjusting and furnace blower.
- Page 4 Photo B INSTALLING THE OXIDIZING UNIT (Return side plenum only) 1. Cut a 1.75” - 2” hole for the unit. 2. Attach the unit to the air duct using the four self-tapping sheet metal screws provided. (Airflow direction is marked on the unit.) 3.
- Page 5 MUV7-50DR shown mounted on a heat pump with the oxidizing unit installed on the air return. Lamp Airflow Optional Odor Control unit 1. Using the lamp mount as a template, draw the hole pattern on the air duct in a suitable location. 8 1/4”...
-
Page 6: Maintenance
MAINTENANCE This maintenance schedule is only a guideline, determined by average conditions. Actual conditions will dictate the frequency of cleaning and/or replacement of lamps. Do not touch the glass portion of the lamps with bare hands because oils from the hands can cause “hot spots” which reduce lamp life. Handle either by the end caps or use a soft cloth. -
Page 7: Troubleshooting
All returns are routed through your wholesaler and must be approved and accompanied by an RGA number. Please call PremierOne Products, Inc. at 800-982-1840 and we will guide you through the return procedure. This warranty gives you specific legal rights and you may also have other rights which vary from state to state. - Page 8 Product; or (b) repair the Product found ing, but not limited to, installation and use of other than a genuine to be defective. In the event that PremierOne elects to repair or PremierOne lamp designed specifically for the Product; (d) failure...
