PremierOne MUV-401H-R Installation & Maintenance Instructions Manual

Multivoltage germicidal air purifier
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

MUV-401H-R MultiVoltage
Germicidal Air Purifier
Installation & Maintenance Instructions
UNPACKING THE UNIT
Verify all parts from the list below are in the box. Each unit is
shipped with the germicidal lamps placed in protective packag-
ing. Do not remove the lamps from the protective packaging
until ready to install. The lamps are fragile and proper care must
be taken when removing from packaging.
The following parts are included:
• MUV-401H-R Unit
• (2) Two germicidal twin lamps
(packed in lamp box)
• (4) Four Sheet Metal Screws
IMPORTANT: SAFETY INSTRUCTIONS
When installing and using this electrical equipment, basic safety precautions
1. READ AND FOLLOW ALL INSTRUCTIONS.
2. SAVE THESE INSTRUCTIONS.
3. Always be sure power is disconnected during installation or service procedures.
4.
The ultraviolet light produced by the UV lamp is harmful to your eyes. Do not look directly at
the lamp. Should it become necessary to view the lamp, use UV-protected goggles.
Lors de l'installation et de l'utilisation de cet équipement, des précautions devront être suivies.
1- Lire et suivre les étapes attentivement.
2- Conserver ces instructions.
3- Assurez-vous toujours que l'alimentation est débranchée pendant les procédures d'installation
ou de maintenance.
4-
Ne pas regarder la lampe directement avec les yeux. Si nécessaire de le faire, veuillez porter
veuillez porter les lunettes de soleil contre les rayons U.V.
Important: Instructions de securité
should always be followed including the following:
• Alcohol pad to clean lamp
• Strain relief connector
• Two caution labels
• Installation & Maintenance Instructions
3099107

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MUV-401H-R and is the answer not in the manual?

Questions and answers

Related Manuals for PremierOne MUV-401H-R

Summary of Contents for PremierOne MUV-401H-R

  • Page 1 The lamps are fragile and proper care must be taken when removing from packaging. The following parts are included: • MUV-401H-R Unit • Alcohol pad to clean lamp • (2) Two germicidal twin lamps • Strain relief connector (packed in lamp box) •...

  • Page 2: Installation

    INSTALLATION: • Do not locate the germicidal lamps in direct sight of plastic material that will be exposed to the UV light, such as wiring, return-side humidifier or certain types of air filters. Check with the filter manufacturer to see if their material is UV resistant.

  • Page 3: Maintenance

    MAINTENANCE This maintenance schedule is only a guideline, determined by average conditions. Actual conditions will dictate the frequency of cleaning and/or replacement of lamps. Do not touch the glass portion of the lamps with bare hands because oils from the hands can cause “hot spots” which reduce lamp life. Handle either by the end caps or use a soft cloth.

  • Page 4: Troubleshooting

    All returns are routed through your wholesaler and must be approved and accompanied by an RGA number. Please call PremierOne Products, Inc. at 800-982-1840 and we will guide you through the return procedure. This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
  • Page 5 MUV-401H-R UVC lamps AIR STREAM can be mounted either on the return or supply side. 15” or 18” 12” OR 16” Germicidal UVC Lamp Box size is 8.75 high x 4.25 wide. 2 3/4”...
  • Page 6 WIRING The multivoltage ballast is self-adjusting and operates with voltages from 120 - 240 VAC. Install provided power cord. For 120V wiring connect the black wire to L1, white wire to neutral, green wire to ground. For 240V wiring install 5 amp in-line fuses to both legs of power, then connect the black wire to L1, white wire to L2, green wire to ground.

  • Page 7: Limited Warranty

    Product; or (b) repair the Product found to be OR OTHER SPECIAL, INCIDENTAL, EXEMPLARY OR CON- defective. In the event that PremierOne elects to repair or replace SEQUENTIAL DAMAGES ARISING OUT OF THE FAILURE OF the Product, such repaired or replaced Product shall be warranted,...
  • Page 8 Product. apply to the customer. This Limited Warranty gives the customer PremierOne warrants that, subject to the exceptions set forth in specific legal rights, and the customer may also have other rights Section 4, above, genuine PremierOne lamps shall function as in- which may vary from jurisdiction to jurisdiction.
