MUV-403H MultiVoltage
Oxidizing UVC System
Installation & Maintenance Instructions
UNPACKING THE UNIT
Each unit is shipped with the 5" lamp installed and the germicidal lamp
placed in a box with protective packaging. Carefully remove lamp from
the tube taking care to not touch the glass portion of the lamp with bare
hands. Oils from the hands can cause "hot spots" which reduce lamp life.
Handle by the end caps or use a soft cloth. If you accidentally touch
a lamp, clean it using the included alcohol cleaning pad or a soft cloth
dampened with rubbing alcohol. The lamp is fragile and proper care
must be taken when removing from packaging.
The following parts are included: • MUV-403H Unit
IMPORTANT: SAFETY INSTRUCTIONS
When installing and using this electrical equipment, basic safety precautions
1. READ AND FOLLOW ALL INSTRUCTIONS.
2. Always be sure the unit is unplugged during installation or service procedures.
3.
The ultraviolet light produced by the UV lamp is harmful to your eyes. Do not look directly at
the lamp. Should it become necessary to view the lamp, use UV-protected goggles.
Lors de l'installation et de l'utilisation de cet équipement, des précautions devront être suivies.
1- Lire et suivre les étapes attentivement.
2- Assurez vous de toujours débrancher avant l installation ou le service.
3-
Ne pas regarder la lampe directement avec les yeux. Si nécessaire de le faire,
veuillez porter les lunettes de soleil contre les rayons U.V.
• Germicidal Twin H Lamp (packed in lamp box)
• Four Sheet Metal Screws
• Installation & maintenance instructions
• 120 VAC Power Cord (PC-120)
• Alcohol pad for cleaning lamps
Important: Instructions de securité
should always be followed including the following:
3099107
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PremierOne MUV-403H-R
Summary of Contents for PremierOne MUV-403H-R
- Page 1 MUV-403H MultiVoltage Oxidizing UVC System Installation & Maintenance Instructions UNPACKING THE UNIT Each unit is shipped with the 5” lamp installed and the germicidal lamp placed in a box with protective packaging. Carefully remove lamp from the tube taking care to not touch the glass portion of the lamp with bare hands.
-
Page 2: Installation
INSTALLATION: If there is a device that creates ozone in the space such as an ionizing air cleaner, it is recommended the oxidizing unit not be used in this application. Use one of our germicidal only models instead. Homes with multiple air handlers: install this unit on the main level air handler and a germicidal only model on the other air handler(s). -
Page 3: Wiring Option
WIRING OPTION 1 The multivoltage ballast is self-adjusting and operates with voltages from 120 - 240 VAC. This unit must cycle with the furnace blower. Install provided power cord and wire the unit to an EAC terminal or current-sensing relay to cycle the unit with the system fan. Connect in accordance with local wiring codes. For 120V wiring connect the black wire to L1 or EAC terminal, white wire to neutral, green wire to ground. -
Page 4: Troubleshooting
All returns are routed through your wholesaler and must be approved and accompanied by an RGA number. Please call PremierOne Products, Inc. at 800-982-1840 and we will guide you through the return procedure. This warranty gives you specific legal rights and you may also have other rights which vary from state to state. - Page 5 10 3/4” INSTALLATION TEM Lamp 4” Use a 2” hole saw to cut 2 openi 1. Cut out area of template indicated by the two circles if using a hole saw. 2. Place template on the return path of the HVAC system and trace the hole pattern for the unit and mark centers for mounting screws.
- Page 6 MPLATE MUV-403H Oxidation Chamber ings indicated by the gray circles. LSK07403H-16/5 LAMP KITS FOR MUV-403H #LSK07403H-16/5 44-Watt UVC/UVV lamp service kit with 16” UV lamp. #LSK07403H-12/5 36-Watt UVC/UVV lamp service kit with 12” UV lamp.
- Page 7 Product; or (b) repair the Product found OR OTHER SPECIAL, INCIDENTAL, EXEMPLARY OR CON- to be defective. In the event that PremierOne elects to repair or SEQUENTIAL DAMAGES ARISING OUT OF THE FAILURE OF replace the Product, such repaired or replaced Product shall be...
- Page 8 Product. apply to the customer. This Limited Warranty gives the customer PremierOne warrants that, subject to the exceptions set forth in specific legal rights, and the customer may also have other rights Section 4, above, genuine PremierOne lamps shall function as in- which may vary from jurisdiction to jurisdiction.
