The following parts are included:
• 503-16 air purifier
• 16" UV-V lamp
• Four self tapping sheet metal screws
• Installation & maintenance instructions
• 120 VAC power cord (PC-120)
• Alcohol cleaning pad
IMPORTANT: SAFETY INSTRUCTIONS
IMPORTANT: Instructions de securité
When installing and using this electrical equipment, basic safety precautions should always be followed including the following:
1. READ AND FOLLOW ALL INSTRUCTIONS.
3. Always be sure the unit is unplugged during installation or service procedures.
4. The ultraviolet light produced by the UV lamp is harmful to your eyes. Do not look directly at
the lamp. Should it become necessary to view the lamp, use UV-protected sunglasses.
Lors de l'installation et de l'utilisation de cet équipement, des précautions devront être suivies.
1- Lire et suivre les étapes attentivement.
3- Assurez vous de toujours débrancher avant l installation ou le service.
4- Ne pas regarder la lampe directement avec les yeux. Si nécessaire de le faire,
veuillez porter les lunettes de soleil contre les rayons U.V.
503-16 MultiVoltage Oxidizing UV-V Air Purifier
This unit is designed for commercial use only.
Never install in a residential setting.
Installation & Maintenance Instructions
Each unit is shipped with the 16" lamp installed in the oxidizing chamber.
UNPACKING THE UNIT
Take care to not touch the glass portion of the lamp with bare hands. Oils
from the hands can cause "hot spots" which reduce lamp life. Handle by
the end caps or use a soft cloth. If you accidentally touch a lamp, clean
it using the supplied alcohol cleaning pad or a soft cloth dampened with
rubbing alcohol. The lamp is fragile and proper care must be taken when
removing for cleaning.
(installed)
Advertisement
Table of Contents
Related Manuals for PremierOne 503-16
Summary of Contents for PremierOne 503-16
- Page 1 503-16 MultiVoltage Oxidizing UV-V Air Purifier This unit is designed for commercial use only. Never install in a residential setting. Installation & Maintenance Instructions Each unit is shipped with the 16” lamp installed in the oxidizing chamber. UNPACKING THE UNIT Take care to not touch the glass portion of the lamp with bare hands.
- Page 2 Commercial buildings only. Suitable for bars, resataurants, dog kennels etc. • Best results are achieved when the unit is installed where the HVAC system air temperature is most constant. INSTALLATION: Therefore, the preferred installation is on the return side of the furnace. If return side installation is not possible, install the unit on the supply side.
- Page 3 The multivoltage ballast is self-adjusting and operates with voltages from 120 - 240 VAC. This unit must WIRING cycle with the furnace blower. Install provided 120 VAC power cord and plug the unit into a 120 VAC outlet which is interlocked with the furnace blower. If a 120 VAC EAC terminal is available, supply power to the outlet from the EAC terminal.
- Page 4 9 3/8” INSTALLATION TEMPLATE 503-16 3 1/4 ” CUT ON DASHED LINE or CUT OUT GREY CIRCLE 1. Cut out area of template indicated by the inside dashed line or the grey c 2. Place template on the return path of the HVAC system and trace the hole patt Unit must be oriented so long dimension is parallel to the direction of the air f 3.
- Page 5 3” circle area if using a 2” hole saw. tern for the unit and mark centers for mounting screws. low. de of unit using the four self tapping sheet metal...
- Page 6 Air flow Box size is 9.375 high x 4.25 wide. Airstream Oxidation Odor Furnace Protective Shield Control 503-16 16” UV-V Lamp Return Air Duct 19 1/2” For Technical Support Call (800)982-1840 © 2016 Form MUV-503/16 (09/28)
