Back View

No. Item
1 Barcode scanner
2 Camera LED flash
3 Rear camera
4 Battery compartment
5 Battery latch release
button
6 Speaker
Description
Scan barcodes.
Provide additional lighting when taking pictures
under low light environment.
Use to take pictures.
Contain the battery.
Press and hold the button to slide the battery
latch to the unlock position.
Emit sound.
