Before You Start

Product Overview

Front View

No. Item
1 Program button
2 Front camera
3 Ambient light sensor
4 Microphone
5 Function button
6 Window button
Description
Tap to enter the chosen program. (user definition)
Use for video conference.
Use to detect the current level of visible light in the
surrounding environment.
Record the surrounding sound.
The button functionality can be assigned via Quick
Menu.
 Scanner button: Press to trigger the Barcode
scan function if the barcode scanner is enabled.
 Camera button: Press to take a picture.
Tap to return to the Start screen.
EN-6
