PROCESS AUTOMATION
Technical Manual
Operation Workstation
VisuNet EX1 Remote Monitor
(RM519)
VisuNet EX1 Panel PC
(PC419)

Advertisement

Table of Contents
loading

Related Manuals for Pepperl+Fuchs VisuNet EX1

Summary of Contents for Pepperl+Fuchs VisuNet EX1

  • Page 1 PROCESS AUTOMATION Technical Manual Operation Workstation VisuNet EX1 Remote Monitor (RM519) VisuNet EX1 Panel PC (PC419)
  • Page 2 Table of Content With regard to the supply of products, the current issue of the following document is applicable: The General Terms of Delivery for Products and Services of the Electrical Industry, published by the Central Association of the Electrical Industry (Zentralverband Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its most recent version as well as the supplementary clause: "Expanded reservation of proprietorship"...

  • Page 3: Table Of Contents

    Table of Content Table of Content Important Information ....................2     General Information ....................2     Safety Instructions ....................3     Differences between PC4xx and RM5xx ............... 4     System Overview of the VisuNet RM/PC in Hazardous Area ......... 5  ...
  • Page 4 Table of Content Information for Positioning VisuNet Devices in Housing with BasicLine Pedestal .. 23     Information for Positioning VisuNet Devices in Housing ........24     8.10 Accessories for Mounting Stainless Steel Case AGx ..........24     8.10.1 Direct Wall Mount Bracket for Stainless Steel Case AGx ............
  • Page 5 Table of Content Accessories ......................... 64     11.1 Box A-10 (Ethernet RJ45 1 Off Patch Field Element) ..........64     11.2 Holder for Barcode Reader ................... 64     11.3 Cables ........................64     11.4 Fuse Set ....................... 64  ...

  • Page 6: Important Information

    Important Information Important Information General Information Copyright 2007-2015 by Pepperl+Fuchs GmbH All rights reserved The publisher reserves the right to alter the information and data contained in this manual without prior notice. Unless otherwise indicated, the company names as well as other names and data used in the examples are purely fictitious.

  • Page 7: Safety Instructions

    Important Information Safety Instructions Please refer to the operation instructions for the safety instructions.

  • Page 8: Differences Between Pc4Xx And Rm5Xx

    Differences between PC4xx and RM5xx Differences between PC4xx and RM5xx The VisuNet product family is a series of rugged operator workstations for the process industry based on high-resolution color graphic LCD monitors. The following table provides an overview of the VisuNet family and its two product lines: Remote Monitor (RM5xx) and Panel PC (PC4xx).

  • Page 9: System Overview Of The Visunet Rm/Pc In Hazardous Area

    System Overview of the VisuNet RM/PC in Hazardous Area System Overview of the VisuNet RM/PC in Hazardous Area...

  • Page 10: Front View Visunet Pc An Visunet Rm

    Front View VisuNet PC an VisuNet RM Front View VisuNet PC an VisuNet RM PC4xx EXTEC LINK RM5xx...

  • Page 11: Rear View Visunet Rm And Visunet Pc

    Rear View VisuNet RM and VisuNet PC Rear View VisuNet RM and VisuNet PC Ex e Ex ib Min. 4mm PA-equipotential bonding conductor Warning! Please refer to the operation instructions for all safety relevant information that must be considered for installation and operation of these devices!

  • Page 12: Connecting And Wiring Diagrams

    Connecting and Wiring Diagrams Connecting and Wiring Diagrams Terminal Compartment X1 (Ex e) (Terminal Pin Assignment) Ethernet Standard version VisuNet RM Standard version VisuNet PC * The interfaces RS 422 and RS 232 can’t be connected at the same time. COM1* COM2 Optional interfaces...

  • Page 13: Network Connection Ethernet (X1)

    Connecting and Wiring Diagrams 6.1.1 Network Connection Ethernet (X1) VisuNet RM and VisuNet PC (10/100 BASE TX Ethernet cable: DATL-CAT71-8-2, recommendation for cable see chap.10.3.1) Version 1: with component: Box-A10 (max over all distance: max. 90m over all) Connection instruction Box-A10 see chap. 9.2 ...

  • Page 14: Wiring Diagram Of The Setup Cable To The Usb Interface (Ex E)

    Connecting and Wiring Diagrams Version 3: with component: Start-up cable S-RJ45/PCEX-1-Setup-Kabel (distance: max. 2,5 m) safe area terminal compartment X1 Ex e white-orange * orange Start-up cable white-green * RJ 45 S-RJ45/PCEX-1-Setup-Kabel Switch Router ... green **Terminal compartment for connection to hub, switch, repeater or router blue/white-blue * brown/white-brown *...

  • Page 15: Terminal Compartment X2 (Ex Ib) (Terminal Pin Assignment)

    Connecting and Wiring Diagrams Terminal Compartment X2 (Ex ib) (Terminal Pin Assignment) Wiring conditions considered acc.EN 60079-14...

  • Page 16: Visunet Rm And Visunet Pc

    VisuNet RM and VisuNet PC VisuNet RM and VisuNet PC Screen VisuNet RM and VisuNet PC The screen has a CCFL backlight. During direct sun exposure the visibility of the display can be reduced. Always protect the system from direct sunlight. An optional touchscreen allows the direct interaction with the application software.
  • Page 17 VisuNet RM and VisuNet PC Power On PC systems can be started by pressing the following key combination: EXTEC Note! Systems built before January 2014 can also be started by pressing the power button. Note! Systems can be switched off with the same key combination when bridge 1 in terminal compartment X2 is closed ( see chapter 6.2).

  • Page 18: Case Design Visunet Rm And Visunet Pc

    Case Design VisuNet RM and VisuNet PC Case Design VisuNet RM and VisuNet PC General Installation Instruction VisuNet RM and VisuNet PC The device must be installed carefully in accordance with the general explosion protection regulations. 19’’ Material front plate: Stainless steel 1.4301 (304) Optional on request: Stainless steel 1.4571 (316Ti) / 1.4404 (316L)

  • Page 19: Cutout For Panel Mounting Visunet 19

    Case Design VisuNet RM and VisuNet PC Cutout for Panel Mounting VisuNet 19” Cutout...
  • Page 20 Case Design VisuNet RM and VisuNet PC...

  • Page 21: Stainless Steel Housing For 19" Visunet Rm And Visunet Pc

    Case Design VisuNet RM and VisuNet PC Stainless Steel Housing for 19” VisuNet RM and VisuNet PC For further technical details please refer to AG1 datasheet. Stainless Steel Housing AG1...

  • Page 22: Rear View Visunet Stainless Steel Case For 19" With Drilling Pattern For Wall Mount Bracket Wall-Bracket5

    Case Design VisuNet RM and VisuNet PC Rear View VisuNet Stainless Steel Case for 19“ with Drilling Pattern for Wall Mount Bracket Wall-Bracket5 (Wall-Bracket5 included in the wall mount version of housing) (all dimensions in mm) (Up to version 12.2010 delivery with 3 x M 20)

  • Page 23: Bottom View Visunet Stainless Steel Case For 19

    Case Design VisuNet RM and VisuNet PC Bottom View VisuNet Stainless Steel Case for 19“ 1 M 20 (for cable gland) 2 M 20 (for cable gland) 3 for PE bolt 4 (for barcode reader optional) Mounting PE Bolt to the Housing (Optional) 1 lock washer 2 washer 3 nut...

  • Page 24: Option - F: Visunet Rm, Visunet Pc 19

    Case Design VisuNet RM and VisuNet PC 8.7.1 Option – F: VisuNet RM, VisuNet PC 19’’ Ø...

  • Page 25: Option - T: Desktop Keyboard To Visunet

    Case Design VisuNet RM and VisuNet PC 8.7.2 Option – T: Desktop Keyboard to VisuNet (or Accessory TASTEX, option T) Warning! The housing must always be connected to the PE. There are 2 possibilities: 1.) Connection via cable shielding of the connecting cable. 2.) Connection via a separate grounding cable (min.

  • Page 26: Keyboard For Panel Mounting

    Case Design VisuNet RM and VisuNet PC 8.7.3 Keyboard for Panel Mounting (Accessory to the product line TASTEX, version N) Keyboard dimension drawing Warning! The housing must always be connected to the PE. There are 2 possibilities: 1.) Connection via cable shielding of the connecting cable. 2.) Build into a metal housing which is connected with the PE.

  • Page 27: Information For Positioning Visunet Devices In Housing With Basicline Pedestal

    Case Design VisuNet RM and VisuNet PC Information for Positioning VisuNet Devices in Housing with BasicLine Pedestal Note! On positioning VisuNet RM/PC devices a distance of min. 700 mm swiveling range between housing and behind wall has to be observed for mounting and opening. A distance of min. 100 mm between housing and left wall has to be observed, too.

  • Page 28: Information For Positioning Visunet Devices In Housing

    Case Design VisuNet RM and VisuNet PC Information for Positioning VisuNet Devices in Housing Note! On positioning VisuNet devices a distance of min. 350 mm swivelling range between housing and left wall has to be observed. Distance min. 8.10 Accessories for Mounting Stainless Steel Case AGx There are the following accessories for mounting VisuNet stainless steel case AGx: Direct wall mount bracket ...

  • Page 29: Direct Wall Mount Bracket For Stainless Steel Case Agx

    Case Design VisuNet RM and VisuNet PC 8.10.1 Direct Wall Mount Bracket for Stainless Steel Case AGx Naming: Wall-Bracket5 (included in the wall mount version of housing) The wall mount bracket has the following dimensions: 4 x M8 Note! On positioning VisuNet devices a distance of min. 350 mm swivelling range between housing and left wall has to be observed.

  • Page 30: Basicline Floor Mount For Stainless Steel Housing Agx

    Case Design VisuNet RM and VisuNet PC 8.10.2 BasicLine Floor Mount for Stainless Steel Housing AGx Order designation: PEDESTAL5-1458-FIX-BL Pedestal fix, stainless steel 1.4301 (304) Note! On positioning VisuNet devices a distance of min. 700 mm swivelling range between housing and behind wall has to be observed for mounting and opening.

  • Page 31: Floor Mount For Stainless Steel Housing Agx

    Case Design VisuNet RM and VisuNet PC 8.10.3 Floor Mount for Stainless Steel Housing AGx Pedestal, fix Order designation: Pedestal5-1458-fix Floor mount: not turnable Material: Stainless steel 1.4301 (304) Optional on request: Stainless steel 1.4571 (316Ti) / 1.4404 (316L) Standard height 1458 mm to center screen...
  • Page 32 Case Design VisuNet RM and VisuNet PC Note! On positioning VisuNet devices a distance of min. 350 mm swivelling range between housing and left wall has to be observed. (refer chapter 8.12 ) Pedestal, turnable Order designation: Pedestal5-1458-turn Floor mount: turnable Material: Stainless steel 1.4301 (304) Optional on request:...
  • Page 33 Case Design VisuNet RM and VisuNet PC Note! On positioning VisuNet devices a distance of min. 350 mm swivelling range between housing and left wall has to be observed. (refer chapter 8.12 ) Pedestal, tilt Order designation: Pedestal5-1458-tilt Floor mount: tiltable Material: Stainless steel 1.4301 (304) Optional on request:...
  • Page 34 Case Design VisuNet RM and VisuNet PC Note! On positioning VisuNet devices a distance of min. 350 mm swivelling range between housing and left wall has to be observed. (refer chapter 8.12 ) Pedestal, turnable and tiltable Order designation: Pedestal5-1458-turn-tilt Floor mount: turnable and tiltable Material: Stainless steel 1.4301 (304)
  • Page 35 Case Design VisuNet RM and VisuNet PC Note! On positioning VisuNet devices a distance of min. 350 mm swivelling range between housing and left wall has to be observed. (refer chapter 8.12 ) Table Housing Order designation: Pedestal5-0528-fix-Y Pedestal fix Material: Stainless steel 1.4301 (304) Optional on request:...
  • Page 36 Case Design VisuNet RM and VisuNet PC Wall Mount Mounting wall bracket to the wall: Dimensions: Possibilities of connection by cable glands: 1 x M16  1 x M20  1 x PE bolt ...
  • Page 37 Case Design VisuNet RM and VisuNet PC Wall Mount, fix Order designation: Support-Arm5-350-350-fix Wall mount: not turnable, stainless steel 1.4301 (304) Note! On positioning VisuNet devices a distance of min. 350 mm swivelling range between housing and left wall has to be observed. (refer chapter 8.12 )
  • Page 38 Case Design VisuNet RM and VisuNet PC Wall Mount, turnable Order designation: Support-Arm5-350-350-turn Wall mount: turnable, stainless steel 1.4301 (304) Swivelling angle Case AG1 without keyboard 320° Case AG1 with keyboard 260° Note! On positioning VisuNet devices a distance of min. 350 mm swivelling range between housing and left wall has to be observed.
  • Page 39 Case Design VisuNet RM and VisuNet PC Wall Mount, tiltable Order designation: Support-Arm5-350-350-tilt Wall mount: tiltable, stainless steel 1.4301 (304 Note! On positioning VisuNet devices a distance of min. 350 mm swivelling range between housing and left wall has to be observed. (refer chapter 8.12 )
  • Page 40 Case Design VisuNet RM and VisuNet PC Wall Mount, turnable and tiltable Order designation: Support-Arm5-350-350-turn-tilt Wall mount: turnable and tiltable, stainless steel 1.4301 (304) Swivelling angle Case AG1 without keyboard (Case justified horizontal) 295° Case AG1 with keyboard (Case justified horizontal) 250°...
  • Page 41 Case Design VisuNet RM and VisuNet PC Ceiling Mount Drilling pattern for mounting ceiling bracket Possibilities of connection by cable glands: 1 x M16  1 x M20  1 x PE bolt ...
  • Page 42 Case Design VisuNet RM and VisuNet PC Ceiling, fix Order designation: Ceiling5-zzzz-fix Ceiling not turnable Material: Stainless steel 1.4301 (304) Optional on request: Stainless steel 1.4571 (316Ti) / 1.4404 (316L) Ceiling height – 1458 =ZZZZ (Example: Ceiling height 3m: 3000-1458 = 1542 = ZZZZ Ceiling5-1542-fix)
  • Page 43 Case Design VisuNet RM and VisuNet PC Note! On positioning VisuNet devices a distance of min. 350 mm swivelling range between housing and left wall has to be observed. (refer chapter 8.12 ) Ceiling, turnable Order designation: Ceiling5-zzzz-turn Ceiling turnable ( +/- 175°) Material: Stainless steel 1.4301 (304) Optional on request:...
  • Page 44 Case Design VisuNet RM and VisuNet PC Note! On positioning VisuNet devices a distance of min. 350 mm swivelling range between housing and left wall has to be observed. (refer chapter 8.12 ) Ceiling, tiltable Order designation: Ceiling5-zzzz-tilt Ceiling tiltable Material: Stainless steel 1.4301 (304) Optional on request:...
  • Page 45 Case Design VisuNet RM and VisuNet PC Note! On positioning VisuNet devices a distance of min. 350 mm swivelling range between housing and left wall has to be observed. (refer chapter 8.12 ) Ceiling, turnable and tiltable Order designation: Ceiling5-zzzz-turn-tilt Ceiling turnable and tiltable Material: Stainless steel 1.4301 (304)
  • Page 46 Case Design VisuNet RM and VisuNet PC Note! On positioning VisuNet devices a distance of min. 350 mm swivelling range between housing and left wall has to be observed. (refer chapter 8.12 )

  • Page 47: Accessories Visunet Rm And Visunet Pc

    Accessories VisuNet RM and VisuNet PC Accessories VisuNet RM and VisuNet PC Barcode Reader The VisuNet RM/PC can operate an intrinsically safe barcode reader at its intrinsically safe TTY interface. The following products can be used: PSCAN-M (radio barcode reader) with PSCAN-B (base station) PSCAN-D (barcode reader) with 5m helix cable Please also refer to the barcode reader operating instructions if one of these intrinsically safe barcode readers is connected.

  • Page 48: Holder For Barcode Reader

    Accessories VisuNet RM and VisuNet PC 9.1.1 Holder for Barcode Reader (with the order of a barcode reader (interface option –S / -A) the holder for the barcode reader is contained in the order) 67.5 All dimensions in mm...
  • Page 49 Accessories VisuNet RM and VisuNet PC Holder for the Barcode Reader at the Case AG1...
  • Page 50 Accessories VisuNet RM and VisuNet PC Mounting the Barcode Reader to Case AG1 1. Screw the two enclosed countersunk head screws tight to the spacer on the AG1 case with an Allen key. Supplementary Upgrade of the VisuNet in AG1 Housing with the Barcode Readers 1.
  • Page 51 Accessories VisuNet RM and VisuNet PC Upgrade of the Socket for the Barcode Reader 18.2 1. Drill-hole M20x1.5 exists in AG1 housing 2. Set 5 drill-holes Ø 3.5, four for the socket of the barcode reader and one for the PA. 1.
  • Page 52 Accessories VisuNet RM and VisuNet PC Upgrade the Holder for Barcode Reader on the AG1 Housing 1. Set 2 drill-holes for the spacer on the AG1 housing...
  • Page 53 Accessories VisuNet RM and VisuNet PC Mounting the Spacer on the Holder for Barcode Reader 1. Tighten the both countersunk head screws with an allan key on the spacer. 1. Washer 2. Lock-washer 3. Cylinder head screw with allen screw 4.

  • Page 54: Box-A10 (Ethernet Rj45 1 Off Patch Field Element)

    Accessories VisuNet RM and VisuNet PC BOX-A10 (Ethernet RJ45 1 Off Patch Field Element) It offers a 1 off Ethernet RJ 45 socket for DIN rail mount. The socket is crimpable to the end of the Ethernet field cable. It is the junction element between the fix installed Ethernet field cable (Cat.6e or Cat.7) and a patch cable to a switch, router or PC.

  • Page 55: Connection Instructions

    Accessories VisuNet RM and VisuNet PC 9.2.1 Connection Instructions Preparation of the BOX-A10 for Installation on a DIN Rail (35 mm) The modules are grounded directly If the module is not supposed to be Then snap the lower housing part on the rail via the ground contact grounded, press the locking latch of the E-DAT REG module onto...
  • Page 56 Accessories VisuNet RM and VisuNet PC Cable Termination Fit a cable tie as strain relief and Insert the white/brown and …and the blue/white and cut off the excess length. white/orange pairs of wires into the green/white pairs of wires into the lower part of the loader…...
  • Page 57 Accessories VisuNet RM and VisuNet PC Installation of the Modules Insert the assembled 8(8) module Attach the housing cover to the top into the lower part of the REG of the lower section and click it housing. downwards into place. Simply fit this terminal onto the rail, The rail must be connected by a screw it tight and connect it to the...

  • Page 58: Technical Data Box A10

    Accessories VisuNet RM and VisuNet PC Disassembly of the Individual Components Press the housing walls gently Loosen the upper housing part with outwards and take out the module. a screwdriver and remove. … and carefully separate the two Lever out the loader with the parts of the housing.

  • Page 59: Connection Instructions Visunet Rm/Pc

    Accessories VisuNet RM and VisuNet PC Mechanical Characteristics Wire connection: Insulation piercing connecting device BTR-IDC: Conductor 0.4 – 0.65 mm AWG 26 – 22 insulation 0.7 – 1.4 mm (1.6 mm) AWG 26/7 stranded wire conductor with 7 Cu strands, uninsulated Can be reused for AWG 22, AWG 23 and AWG 24, providing an identical or larger cross- section is selected.

  • Page 60: Pc Keyboard Intrinsically Safe (Components Optional)

    Accessories VisuNet RM and VisuNet PC Order when Connecting Note! When connecting please check that the pairs of wires are twisted till near the clamp. Example: PC Keyboard Intrinsically Safe (Components Optional) The intrinsically safe keyboards integrate different mouse systems. The dimensions are the same for all versions.

  • Page 61: Installation Visunet Rm And Visunet Pc

    Installation VisuNet RM and VisuNet PC Installation VisuNet RM and VisuNet PC 10.1 General Instructions and Explosion Protection Requirements Cables are only allowed to be connected when de-energized. Make sure that all terminal compartments are tightly sealed in accordance with regulations prior to starting up the equipment.
  • Page 62 Installation VisuNet RM and VisuNet PC We recommend using a Cat. 7 cable because it offers the best results, especially in an industrial environment. In addition to the cable quality, transmission reliability can be negatively affected by four other factors: EMC, e.g.
  • Page 63 Installation VisuNet RM and VisuNet PC If the ping works but you cannot establish an Ethernet connection VisuNet PC and VisuNet RM Remedy: Check the firewall settings on the host, switch or router...

  • Page 64: Usb (Ex E)

    Installation VisuNet RM and VisuNet PC 10.3.2 USB (Ex e) Paired data cable for fixed mounting with copper braiding and a cross-section of 0.75 mm², e.g. LiYCY (TP) 2 x 2 x 0.75. The maximum cable length is 5 m. 10.3.3 RS 422 (Ex e) Paired data cable for fixed mounting with copper braiding and a cross-section of 0.75 mm²,...

  • Page 65: Visunet Power Supply Cable (24V Dc)

    Installation VisuNet RM and VisuNet PC 10.3.9 VisuNet Power Supply Cable (24V DC) DC Power supply cable Part code: Order number Cable length Information DATL-A2-2.5-1 205285 up to 80m DATL-A2-2.5-1-Flex 205286 up to 80 m If the VisuNet is ordered in a (flexible cable 2 x 2.5 mm case AGx and additional with a turnable accessory for...
  • Page 66 Installation VisuNet RM and VisuNet PC Example 1: If a low-impedance equipotential bonding system (building grounding system) is effective under all operating conditions, both ends of the shield must be connected and grounded. Caution is necessary, however, if transients that cannot be statically measured are produced when machines are switched.

  • Page 67: Assembly Instructions For Ex Emc Cable Glands

    Installation VisuNet RM and VisuNet PC 10.4.2 Assembly Instructions for Ex EMC Cable Glands The supply cables for the Ex e Ethernet and the RS485 or TTY Ex e data interface, the Ex i keyboard and the Ex i scanner must be shielded, in order to ensure sufficient immunity to interference (EMC).

  • Page 68: Accessories

    Accessories Accessories 11.1 Box A-10 (Ethernet RJ45 1 Off Patch Field Element) Order code Box-A10 Order number Box-A10-Kat.7-RJ45-Mini Patch 520242 11.2 Holder for Barcode Reader Order code holder for barcode reader Order number Scanner-Holder-Visunet-RM/PC 208140 11.3 Cables Order code Power supply cable Order number Variants see chap.

  • Page 69: Pedestal/Support-Arm/Ceiling

    Accessories 11.6 Pedestal/Support-Arm/Ceiling Order code Order number Pedestals PEDESTAL5-1458-FIX 198769 PEDESTAL5-1458-TURN 198770 PEDESTAL5-1458-TILT 198771 PEDESTAL5-1458-TURN-TILT 198772 Table housing PEDESTAL5-0528-FIX-Y 203537 Support-arms Support-Arm5-350-350-fix 198777 Support-Arm5-350-350-TURN 203401 Support-Arm5-350-350-TILT 198779 Support-Arm5-350-350-TURN-TILT 203402 Ceilings CEILING5-ZZZZ-FIX 198773 CEILING5-ZZZZ-TURN 198774 CEILING5-ZZZZ-TILT 198775 CEILING5-ZZZZ-TURN-TILT 198776 11.7 Pedestal BasicLine Order code Order number Pedestal BasicLine...

  • Page 70: Packing Set: Visunet Front Plate Protection

    Accessories 11.9 Packing Set: VisuNet Front Plate Protection Order code front plate protection Order number For 19“ devices: SPARE-PROTECTPLATE-VISUNET-EX1-19 221502 For 15“ devices: SPARE-PROTECTPLATE-VISUNET-EX1-15 228546 Protect plate Protect plate mounted...

  • Page 71: Replace A Blown Fuse

    Replace a Blown Fuse Replace a Blown Fuse (Fuse set: FUSE-RM5/PC4-1ATL) Disconnect device from power supply and wait at least three minutes Unscrew the four screws of the Ex-e terminal box with an appropriate tool and open the Ex-e terminal box by removing the cover.

  • Page 72: Dictionary For Visunet

    Dictionary for VisuNet Dictionary for VisuNet 10Base-T Network card capability 10 MBit/s, Baseband (one signal per time), Twisted pair cable 100Base-TX Network card capability 100 MBit/s, Baseband (one signal per time), Twisted pair cable, max 100m per segment 100Base-FX Network card capability 100-1000 MBit/s, Baseband (one signal per time), Fibre Optic cable, usually multimode fibre...
  • Page 73 Dictionary for VisuNet Ethernet Network definition global Definition for distributed, packet- switching, local computer networks (IEEE 802.3), e.g. it defines the use of Twisted Pair cables (physical Layer), its connectors (physical layer) and the use of the CSMA/CD standard (connection layer). speed 10MBit/s, 100MBit/s, 1000MBit/s, topology: Star Fast Ethernet...
  • Page 74 Dictionary for VisuNet ISO / OSI reference model Is an Open System Interconnection standard, introduced by the International Standardisation Organisation (ISO) in 1984. It consist of 7 layers to represent the different levels of communication in a very general form. Layer 1 is the physical layer and specifies e.g.
  • Page 75 Dictionary for VisuNet far distant PC, e.g. through a network. TCP/IP is usable as transport protocol. Network Operating Microsoft Windows XP Pro, Windows System 2000 Server, Windows 2003 Server, Novell NetWare offer the functionality for Client/Server Networks Repeater Network Hardware Is an active device which refreshes and amplifies the network signals in a cable (ISO-OSI Level...
  • Page 76 Dictionary for VisuNet transportation to the correct destination in the Internet Alternatively used to TCP Cable Type Unshielded Twisted Pair cable W-LAN Network Type Wireless Network Network Type Wide Area Network, also MAN (Metropolitan Area Network) and GAN (Global Ara Network) WiFi organisation Wireless Fidelity.
  • Page 77 Notes...
  • Page 78 Notes...
  • Page 79 Notes...
  • Page 80 Notes 266858 / TDOCT-3675AENG 01/2015...
