RMG GSM-SPAT Installation Manual

Three Phase GSM Mobile Motor Pump Controller with all Safety
Protection, Alerts & Timer Features (Mobile Motor Starter)
The GSM Mobile Starter is used to switch ON or OFF your motor pump from anywhere in the
world. It will control your motor pump via SMS or giving CALL.
SIMPLE COMMANDS FOR MOTOR ON/OFF CONTROL WITH YOUR MOBILE
SMS COMMAND
S.No.
TO GSM SIM
1 00
2 10
3 11
4 12
5 13
6 14
7 70
8 71
9 80
10 81
11 90
12 9XY
13 *
14 LC0
15 LC1
16 FD0
17 FD1
18 ASET
19 OLXX
20 ULXX
21
STX-HH:MM,HH:MM
22 SCT
22 T-HH:MM
Web: www.rmgautomation.com
EXAMPLE
00
It denotes the Power ON time.
10
It will switch OFF the motor pump.
11
It will switch ON the motor pump.
12
It gives the ON/OFF status of your motor pump.
It Disables AUTO ON operation. It will not Switch ON the
13
motor pump when the power resumes.
It Enables AUTO ON operation. It will Switch ON the
14
motor pump when the power resumes.
70
Activates for ANY USERS.
71
Activates for REG. USERS.
80
It disables the AUTO REPLY SMS facility.
81
It enables the AUTO REPLY SMS facility.
90
It gives the registered users list.
919940594413 It helps to store the user numbers (X-User 1, 2, 3, 4, 5
92YYYYYYYYYY YYYYYYYYYY-Mobile number). It is same for 4
93YYYYYYYYYY user (94YYYYYYYYYY and 95YYYYYYYYYY)
*
It helps us to know the setting status.
LC0
It disables 3-Phase Line Checking
LC1
It enables 3-Phase Line Checking
FD0
It disables Feedback Alert for Manual Motor ON / OFF
FD1
It enables Feedback Alert for Manual Motor ON / OFF
It enables for Automatic Current Setting for Overload and
ASET Dry Run. This command functions only when motor is
running.
It helps to enter the overload current setting manually.
OL15
Eg. 15 Amps is set as Overload Current.
It helps to enter the underload current setting manually.
UL05
Eg. 5 Amps is set as Underload Current.
ST1-06:00,06:30
ST2-19:00,19:30
ST3-11:15,11:45 It helps to schedule the ON time and OFF time. Totally 5
ST4-08:00,09:30 slots can be scheduled. (Note – Use 24 hour format)
ST5-22:00,05:00
SCT
It lists the scheduled time slots.
It helps us to use as a Delay / Stop Timer. Motor get ON
T-00:20 once the time is set and will get switched OFF after the set
time is over. Eg. After 20 minutes, motor will get OFF.
eMail: rmgworld@hotmail.com
GSM-SPAT - Installation Manual
DESCRIPTION
Mobile: +91 99405 94413
and 5
