- Page 1 Gas Pressure Regulator RMG 214 (D 144a) 214.20 Operation and Maintenance, Spare Parts edition 07/2003 Serving the Gas Industry - WORLDWIDE...
- Page 2 214.20 p.02...
- Page 3 2. Special Operating Instructions valve seat diameter Take care that not more than the permissible inlet pressure prevails on the inlet side of the RMG 214 as to avoid damage to internal parts valve seat diameter 6 mm...
- Page 4 NOTE: When mounting the spring housing take care not to tighten the lid too strongly. Only apply enough force to press the diaphragm down for not more than 1 mm. This is sufficient to achieve tightness. 214.20 p.04...
- Page 5 Spare Parts RMG 214 Spare Parts Drawing 4.1.1 Version with internal measuring impulse connection internal safety relief valve 20 W 22 W W 28 W 31 parts marked are to be kept in stock for maintenance. 214.20 p.05...
- Page 6 RMG 214 spare parts drawing 4.1.2 version with external measuring line integrated safety relief valve 20 W 22 W W 28 54 W W 31 W 51 56 W W 11 W 12 214.20 p.06 parts marked are to be kept in stock for maintenance.
- Page 7 RMG 214 spare parts drawing 4.1.3 back-flow proof version, only for valve seat dia. 6 mm parts marked are to be kept in stock for maintenance. 214.20 p.07...
- Page 8 4.2 spare parts list RMG 214 pos.- description amount material RMG part no. gauge, at option: 0 to 400 bar 00 026 772 0 to 100 bar 00 026 479 intermediate piece 10 015 185 sealing ring at option: 0,5 mm thick...
- Page 9 RMG part no. hexagonal nut 18 353 938 gauge or Verschluflschraube gauge, at option: 0 to 10 bar 00 026 281 0 to 25 bar 00 026 284 0 to 60 bar 00 026 283 0 to 100 bar...
- Page 10 214.20 p.10...
- Page 11 214.20 p.11...
- Page 12 Telephone (++49) 561 5007-0 • Fax (++49) 561 5007-207 design and assembly of gas pressure regulating and metering stations The RMG Group of Companies on the internet: http://www.rmg.de Serving the Gas Industry - WORLDWIDE We reserve the right for technical changes...
