A.

INTRODUCTION

1. Congratulations: Thank you for purchasing TPI products. The SP565 is easy to use
and built to last. It is backed by a 3 year limited warranty.
2. Product Description: The SP565 is a hot wire air velocity "Smart Probe". It connects to
your mobile device and uses the TPI View App to display airflow & temperature
readings. Reports can be saved and e-mailed or shared from the app.
B.

SAFETY CONSIDERATIONS

1. Never insert the sensor into hot air.
2. Never allow a foreign object into the sensor cage. The sensor may be damaged.
3. Do not expose the unit to damp environments for extended
periods of time.
C. SPECIFICATIONS
Sensor Type
Air velocity Measurement Range
Air Velocity Accuracy
Resolution
Temperature Measurement Range
Temperature Accuracy
Units of Measure
Operating Temperature
Communication
Battery Type
Battery Life
CFM Calculation
The SP565 has been tested with the following standards and is in compliance with the council
RED directive 2014/53/EU: -
EN 62479:2010
EN 61326-1:2013
EN 61010-1:2010
ETSI EN 301 489-17 V3.1.1(2017-02)
ETSI EN 301 489-1 V2.1.1 (2017-02)
ETSI EN 300 328 V2.2.0 (2017-11)
The relevent certificate can be viewed, downloaded and printed from the TPI
website at the following address: -
www.tpieurope.com/wp-content/uploads/2019/11/SP565-Certificate-of-Conformity.pdf
SP565 Smart Probe Air Velocity Meter Specifications
Hot wire
40 ft/min to 3900 ft/min (0.2 m/s to 20 m/s)
+/-(5% of rdg + 10 digits) or +/-(1% FS + 10 digits)
2 ft/min / 0.01 m/s
-40°F to 140°F (-20°C to 60°C)
+/-1°F(0.5°C) (32°F to 113°F / 0°C to 45°C)
+/-2°F(1°C) <32°F(0°C) and >113°F (45°C)
m/s, km/s, ft/min, miles/hr, knots/hr
-4°F to 122°F (-20°C to 50°C)
Bluetooth version 4.2 (Use with TPI Smart Probe App)
AAA x 3
14 hours typical
Performed via TPI Smart Probe App
