1.

Introduction

The LMP91051 Design Kit (consisting of the LMP91051 Evaluation Module, the SPIO-4 Digital Controller
Board, the Sensor AFE software, and this user's guide) is designed to ease evaluation and design-in of Texas
Instrument's LMP91051 Configurable AFE for Nondispersive Infrared (NDIR).
Data capturing and evaluations are simplified by connecting the SPIO-4 Digital Controller Board (SPIO-4 board)
to a PC via USB and running the Sensor AFE software. The data capture board will generate the SPI signals
to communicate to and capture data from the LMP91051. The user will also have the option to evaluate the
LMP91051 without using the SPIO-4 board or the Sensor AFE software.
The on board data converter will digitize the LMP91051's analog output, and the software will display these
results in time domain and histogram. The software also allows customers to write to and read from registers,
to configure the device's gain, output offset, and common mode voltage, and most importantly, to configure and
learn about the LMP91051.
October 2012
All manuals and user guides at all-guidesbox.com
LMP91051EVM User's Guide
LIST OF FIGURES
LIST OF TABLES
User's Guide
October 2012
LMP91051EVM User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ROCKSTAND and is the answer not in the manual?

Questions and answers

Summary of Contents for Texas Instruments ROCKSTAND

  • Page 1: Table Of Contents

    All manuals and user guides at all-guidesbox.com User’s Guide October 2012 LMP91051EVM User’s Guide CONTENTS INTRODUCTION ....................1 SETUP ........................2 OPERATION ......................5 INSTALLING THE SENSOR AFE SOFTWARE ........... 10 BOARD LAYOUT ....................11 SCHEMATIC ....................... 12 BOM ........................13 LIST OF FIGURES Connection Diagram ....................
  • Page 2: Setup

    All manuals and user guides at all-guidesbox.com This document describes the connection between the boards and PC, and provides a quick start for voltage measurements. This document also describes how to evaluate the LMP91051 with and without the SPIO-4 board and provides the schematic, board layout, and BOM. Setup This section describes the jumpers and connectors on the EVM as well and how to properly connect, set up and use the LMP91051EVM.
  • Page 3: Jumper Setting (Default) For Voltage Reading

    All manuals and user guides at all-guidesbox.com Figure 2: Jumper Setting (Default) for voltage reading Table 1: Jumpers for Voltage Measurement Jumpers Purpose JP1: VDD_DUT P1-P2 Connect LMP91051 VDD to +3.3V from SPIO4 JP2: VREF_ADC P1-P2 Connect ADC VREF to 4.1V from U5 (LM4140) JP3: VA_ADC P1-P2 Connect ADC VA to +5V from SPIO4...
  • Page 4: Lmp91051Evm To Spio-4 Board Connection

    All manuals and user guides at all-guidesbox.com 2.3. Installing/Opening the Software Follow Section 4 to install and open the Sensor AFE software. 2.4. Connecting and Powering the Boards These Steps have to be done in this order. 1. Connect the LMP91051EVM’s J3 to SPIO-4 Board’s J6. See Figure 3. Figure 3: LMP91051EVM to SPIO-4 Board Connection 2.
  • Page 5: Operation

    All manuals and user guides at all-guidesbox.com Operation 3.1. Sensor AFE Software Overview Once connection between the boards and PC is established, you can use the software to communicate to and capture data from the LMP91051. Drag cursor over window icons to get an icon description. Some items of interest are shown in Figure 4.
  • Page 6 All manuals and user guides at all-guidesbox.com Documentation: Accesses the LMP91051 Datasheet, SPIO4 User’s Guide, or Evaluation Board User’s Guide. 2. Device Selection and User Inputs a. LMP91050/1 : Toggle between LMP91050 and LMP91051 device. b. fc: Center frequency of external bandpass filter. c.
  • Page 7: Recommended Lmp91051 Configuration For A Voltage Reading

    All manuals and user guides at all-guidesbox.com Figure 5: Recommended LMP91051 Configuration for a voltage Reading 1. Step 1: Select a Sensor – Sensor Database window opens. See Figure 6. Step 1: Click sensor type (Thermopile) and the sensors will show in the bottom table. Step 2: Click sensor and then click “Select”...
  • Page 8: Sensor Database Window

    All manuals and user guides at all-guidesbox.com Step 1 Step 2 Figure 6: Sensor Database Window 2. Step 2: Input Mux – click on the mux block to set “1: IN1” (default). 3. Step 3: PGA1 Enable – click on the “PGA1” block to set “1: PGA1 ON” . Remember after configuring the register map to use the Write All Registers button to update the registers.
  • Page 9: Reults Of Dc Reading

    All manuals and user guides at all-guidesbox.com 3.3. Capturing Data 1. Click on the “Measurement” tab. 2. Under the “Output Format” field, select Display as “Output Voltage (V)” 3. Under the “Stop Condition” field, select Run as “1” Seconds. Alternatively, select “Run Continuously”...
  • Page 10: Installing The Sensor Afe Software

    All manuals and user guides at all-guidesbox.com 3.5. Evaluating the LMP91051 without the SPIO-4 Board The SPIO-4 digital controller board is used to generate the SPI signals to communicate to the LMP91051. Without the SPIO-4 board, the Sensor AFE software for the LMP91051 cannot be used to capture and analyze data from the LMP91051EVM.
  • Page 11: Board Layout

    All manuals and user guides at all-guidesbox.com 3. Installing the Software a. See the provided Installation Guide for LMP91050 SensorAFE Software.pdf i. Note: If you run the software without the boards, you’ll get an error message. Ignore that error message and click “Ok” to continue. Board Layout Figure 9: LMP91051EVM Layout LMP91051EVM User’s Guide...
  • Page 12: Schematic

    All manuals and user guides at all-guidesbox.com Schematic Figure 10: LMP91051EVM Schematic...
  • Page 13: Bom

    All manuals and user guides at all-guidesbox.com LMP91051EVM Bill of Materials Item Designator Description Manufacturer PartNumber Quantity +3P3V, +5V, A0_DUT, A1_DUT, CMOUT_DUT, CSB_ADC, Test Point, TH, Compact, Red Keystone Electronics 5005 CSB_DUT, DOUT_ADC, IN1_DUT, IN2_DUT, MISO, MOSI, MOSI_EN, OUT_DUT, REF_ADC, SCLK_ADC, SCLK_DUT, SDIO_DUT, TEMP, VA_ADC, VDD_DUT, VDD_EXT, VIO, VIO_ADC, VIO_EXT, VREF_ADC Printed Circuit Board...
  • Page 14 0603 RES, 51.1 ohm, 1%, 0.1W, Vishay-Dale CRCW060351R1FKEA 0603 R11, R12, R13, R14 Vishay-Dale CRCW06031R00JNEA LMP91051 Texas Instruments LMP91051 16-Bit, 50 to 250 kSPS, Texas Instruments ADC141S628QIMMX/NOP Differential Input, MicroPower ADC, 10-pin Mini SOIC, Pb- Free Non-Inverting 3-State Buffer Texas Instruments...
