LAUNCH
Power adaptors
5
B-shaped terminal
to Micro USB
6
cable
Type A to Micro
7
USB cable
Crossover cable
8
Non-16pin
adaptor cable kit
9
for commercial
vehicles
1.3 Components & Controls
There are two main components to the diagnostic system: display tablet and VCI
device.

1.3.1 Display tablet

The tablet acts as the central processing system, which is used to receive and
analyze the live vehicle data from the VCI device and then output the test result.
HD15M to OBD II adaptor.
To charge the tablet through
connection to AC outlet.
To connect the VCI module and
diagnostic tool to perform vehicle
diagnosis.
To connect the tablet to PC for data
exchange.
Connects the VCI module for
firmware upgrade.
Check the package box for detailed
non-16pin adaptor cables.
3
3
1
1
1
(Optional)
