USER MANUAL: ALX-ELITE
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT

Installation Requirements

Electrical
• 110 VAC, 5A, Single Phase, 50-60 Hz
• NEMA 5-15 GFCI Protected Outlet
• Surge suppression recommended
Network
• Cat 5e or higher Ethernet cable connection (field-
wired sealed plug included with unit)
-OR-
• WiFi (802.11n or 802.11b/g), WPA security
Compressed Air (typical installation)
• Clean, dry air
• 10 CFM (283 L/min) @ 80 psi (5.5 bar) minimum
• 100 psi (6.9 bar) maximum supply pressure
• Recommended regulator setting: 80 PSI (5.5 bar).
Water Supply (typical installation)
• Cold Portable Water
• 7 GPM (26.5 Lpm) @ 35 psi (2.5 bar) minimum
• 100 psi (6.9 bar) maximum supply pressure
• Recommended regulator setting: 50 PSI (3.4 bar).
NOTE:A back flow preventer must be installed
in the water supply to this unit, per local codes.
Page 4 of 33 ALX-ELITE User Manual Last Update: 03/24/2021
