Network Setup

1. Login as an administrator.
2. Use ↑ and ↓ keys to select Network Setup
and press ENTER.
3. Select an option and press ENTER:
Ethernet Config and Status
1. Select Ethernet Config and press ENTER
2. Select Config: and use → and ← keys to change
between DISABLE, STATIC and DHCP
3. If STATIC was selected, enter the IP, GW
(Gateway), MASK and DNS
4. Press ESC
5. Select Ethernet Status to verify the
connectivity:
• Down-Offline - No network connection
• Up-Online - Network connected
WiFi Config and Status
1. Select WiFi Config and press ENTER
2. Select Config: and use → and ← keys to change
between DISABLE, STATIC and DHCP
3. Enter an SSID: (name of the network).
4. Select WPA: and Press → or ← for YES or NO
5. Select PASS: and enter the network password
6. If STATIC was selected, enter the IP, GW
(Gateway), MASK and DNS.
7. Press ESC
8. Select WiFi Status to verify the connection:
• Down-Offline - WiFi is connected but there
is no network connection
• Up-Offline - WiFi network connection
established but no communication
• Up-Online - WiFi is connected and is
communicating
Page 19 of 33 ALX-ELITE User Manual
Network Setup
Ethernet Status
Ethernet Config
WiFi Status
WiFi Config
Ethernet Config
Config:
eth0: Down - Offline
IP: 000.000.000.000
GW: 000.000.000.00
MASK:000.000.000.000
WiFi Config
Config:
SSID: Example
WPA:
PASS: eXampl3
WiFi: Up
IP: 192.168.002.202
GW: 192.168.002.001
MASK:255.255.255.000
TIP: If Ethernet or WiFi are not being used, make
sure to set them to DISABLED. This will allow
faster boot-up times.
