USER MANUAL: ALX-ELITE
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT

Overview

The ALX-ELITE is a chemical management
controller that can dispense chemicals according
to programmable recipes (Applications). Access to
Applications can be restricted on a per-user basis over
a rolling time period. Users can be required to use
a 4-digit login passcode or RFID card to login before
dispensing Applications. This allows tracking and
recording of chemical usage by User. The ALX-ELITE
will generate and e-mail Reports on demand or on
a daily, weekly or monthly basis. Reports can also
be downloaded to a USB flash drive for immediate
viewing. All configuration of the ALX-ELITE can be
performed using the built-in keypad and character
display. The ALX-ELITE will also broadcast a local WiFi
network which allows access to the web-browser
based System Editor for configuration using a laptop.

Terminology

• Users - The people who will be using the system
to dispense Applications. Up to 999 users can be
stored.
• Permissions - Control the number of times
each User can access each Application. Can be
disabled.
• Devices - The physical outputs and/or inputs that
connect to the controller to perform a function.
The ALX-ELITE is compatible CAN-SO-1 and CAN-
SO-4 solenoid valve output devices.
• Applications - Recipes which determine the type
and sequence of Dispense Steps. Up to 999
recipes can be stored.
• Dispense Steps - Segments of an Application that
determine which output Device will be energized
and for how long. Each Application can contain up
to 6 Steps.
• Fixed Time Step - Will energize an output Device
for a specified amount of time. Reported Step
volume must be manually entered.
• Calibrated Step - Uses Device Calibration to
determine how long an output Device should be
energized, based on a specified target volume.
Page 3 of 33 ALX-ELITE User Manual

Specifications

Software
• Maximum number of Users: 100
• Maximum number of Applications: 999
• Maximum Dispense Steps per Application: 6
• Dispense Step time range: 00.1s - 99m:99.9s
• Permissions time range: 1-24 hours
• Max Permissions count: 99
Hardware
• Maximum number of Devices: 16*
• Dimensions: 12" x 10" x 7"
NOTE: A single CAN-SO-4 counts as 4 Devices.
Acceptable Chemical Products
• Acids
• Caustics
• Sanitizers
• Chlorine
Acceptable RFID Card Types:
ProxCard® II
ISOProx® II
DuoProx® II
Smart ISOProx®
DuoProx® II
NOTE: Only Prox® RFID cards are accepted.
iClass cards will not register.
Proximity®
ProxCard® Plus
ProxKey® II
MicroProx®
MIFARE®
Last Update: 03/24/2021
