Applications

Adding an Application
1. Log in as an administrator.
2. Use ↑ and ↓ keys to select Applications and
press ENTER.
3. Select 00-Add New App and press ENTER.
4. Enter a 3-digit Access Code and a Name.
NOTE: Each Application must have a unique
3-digit code.
5. Select Add dispense step and press ENTER.
6. Select a Device. The Device name will be
displayed below.
7. Select a Dispense Type and Time/Volume:
• Fixed Time - Will energize the Device for
the amount of time specified in the Time:
field and requires Volume: to be manually
entered for Reporting purposes.
• Calibrated - Requires Volume: to
be manually entered and uses the Device
Calibration to automatically calculate and fill
in the Time: field.
NOTE: If the Device does not have at least one
calibration point, the Time: field will remain
at 00m:00s and the Application will not run!
NOTE: If the Device is configured as a Piston
Pump, the Type: field will show Piston
Pump. Volume: must be manually entered
and Time: is automatically calculated.
8. Press ESC to return to previous screen.
9. Repeat steps 5-7 above to add more dispense
steps or press ESC if finished.
10. When prompted to save changes, press ← for Yes
or → for No.
Page 14 of 33 ALX-ELITE User Manual
Edit Applications
>000-Add New App
001-Demo App 1
Editing Application
App# 123
Name:Demo App 2
>Add dispense step
App# 123 Step# 1
Device #0689
Name:Water (Red)
Type: Calibrated
Time: 00m:15s
Volume:
000.50GAL 000.00 oz
Editing Application
App# 123
Name:Demo App 2
Step#1-Water (Red)
Step#2-Demo Chemic
Add dispense step
(DELETE App)
