EX-1186HMVS-2
3. Layout, Connections & Jumper Settings
3.1 Layout
Front Side:
7-24V T-Block for optional
Power LED
7-24V DC-Connector for
optional Power Supply
3.2 Connectors
+7V to +24V T-Block:
GND (Ground)
+7V - 24V
© Copyright 2022 by EXSYS Vertriebs GmbH. All Rights Reserved
Power Supply
Downstream A-Port
ATTENTION!!!
Never connect power to GND, it will destroy
your Hardware!!!
4x USB 3.2 Gen 1
11
English
1x USB 3.2 Gen 1
Upstream B-Port
