Z-WAVE® RANGE TESTING
8.1 - Z-Wave® range test
The device has a built in Z-Wave® network main controller range tester.
Note
To perform a Z-Wave® range test, the device needs to be added to the Z-Wave® controller. Testing is recommended only in special cases, as
it can stress the network.
8.2 - Main controller range test
1. Press and hold the maintenance button to enter the menu.
2. Release the button when the LED indicator light glows in magenta.
3. Quickly click the button to confirm.
4. LED indicator light indicates the Z-Wave® network range (range signaling modes are described in table A4 below).
5. To exit the Z-Wave® range test, press the button briefly.
8.3 - Z-Wave® range tester signaling modes
Table A4 - DoubleSmart-Control - Z-Wave® range tester signaling modes
Color Status
Pulsing
Green
Glowing
Pulsing
Yellow
Glowing
Violet Pulsing
Red Glowing
Note
Communication mode of the device may switch between direct and routing, especially if the device is on the limit of the direct range.
8
The device attempts to establish a direct communication with the main controller.
If such attempt fails, the device tries to establish a routed communication through other modules, which is sig-
naled by the LED indicator light pulsing yellow.
The device communicates with the main controller directly.
The device tries to establish a routed communication with the main controller through other modules (repeaters).
The device communicates with the main controller through other modules.
After 2 seconds the device retries to establish a direct communication with the main controller, which is signaled
by the LED indicator light pulsing green.
The device communicates at the maximum distance of the Z-Wave® network.
If connection proves successful it's confirmed with the LED indicator light glowing yellow. It's not recommended
to use the device at the range limit.
The device isn't able to connect to the main controller directly or through another Z-Wave® nework device (re-
peater).
Description
