Summary of Contents for Nice DoubleSmart-Control
- Page 1 DoubleSmart-Control Turning electrical devices or circuits on or off remotely EN - Instructions and warnings for installation and use v4.5...
-
Page 2: Warnings And General Precautions
GENERAL INFORMATION ABOUT NICE Z-Wave® SYSTEM The NICE DoubleSmart-Control is a wireless smart home automation system, based on the Z-Wave® protocol. All the available devices can be controlled using a computer (PC, Mac), smartphone or tablet. Z-Wave® devices can receive and repeat the signal, increasing the Z-Wave®... -
Page 3: Product Description
PRODUCT DESCRIPTION The remotely operated NICE DoubleSmart-Control is designed to turn electrical devices or circuits on and off. DoubleSmart-Control enables the control of two devices or a circuit. The compact size of this product enables its installation in the housings of other devices. -
Page 4: Installation
7. Now add the device to the Z-Wave® network (see chapter 5). 100-240V AC 24-30V DC S1 S2 Q1 IN Figure 1: Example connection of DoubleSmart-Control • S1 - 1 button terminal • S2 - 2 button terminal • L - live lead terminal •... - Page 5 ADDING TO AND REMOVING FROM Z-WAVE® NETWORK 5.1 - Adding device to Z-Wave® (Inclusion) It's the Z-Wave® device learning mode. It enables adding the device to an existing Z-Wave® network. 5.1.1 - Adding device to Z-Wave® manually 1. Power on the device. 2.
- Page 6 The device can activate scenes in the Z-Wave® controller by sending the scene ID and an attribute of a specific action using Central Scene Command Class. By default all actions are activated. Change settings of parameters 40 and 41 to disable scene activation for selected actions. Table A1 - DoubleSmart-Control - Activating scenes Switch Action...
- Page 7 Values are sent using Basic Command Class. Values in table A3 below are the default values and they can be adjusted using parameters 156-161. Table A3 - DoubleSmart-Control - Values sent to association groups depending on settings Parameter 156/157 Parameter 159/160...
- Page 8 4. LED indicator light indicates the Z-Wave® network range (range signaling modes are described in table A4 below). 5. To exit the Z-Wave® range test, press the button briefly. 8.3 - Z-Wave® range tester signaling modes Table A4 - DoubleSmart-Control - Z-Wave® range tester signaling modes Color Status Description The device attempts to establish a direct communication with the main controller.
-
Page 9: Factory Settings Reset
FACTORY SETTINGS RESET Reset procedure allows to restore the device back to its factory settings, which means all information about the Z-Wave® controller and user configuration is deleted. Make sure that restoring the factory settings doesn't damage the connected device. We recommend disconnecting the device first. Note Resetting the device isn't the recommended way of removing the device from the Z-Wave®... -
Page 10: Advanced Parameters
The settings can be adjusted through the Z-Wave® controller to which the device is added. The way of adjusting settings might differ depend- ing on the controller. In this interface the parameters are presented as simple options in Advanced Settings of the device. Table A5 - DoubleSmart-Control - Advanced parameters Default Parameter... - Page 11 Table A5 - DoubleSmart-Control - Advanced parameters Default Parameter Parameter Description Available setting setting size 1B [MSB] – Notification Type [0x04, 4 [bytes] This parameter determines which 2B – Notification Status 0xFF, 0x00, alarm frames the device should 3B – Event/State Parameters 0x00] 34.
- Page 12 Table A5 - DoubleSmart-Control - Advanced parameters Default Parameter Parameter Description Available setting setting size 156. S1 input – This parameter defines the value 0 – turn off 2 [bytes] Switch ON value sent with the Switch ON command 1-99 – turn on and set level...
- Page 13 COMMAND_CLASS_SUPERVISION [0x6C] COMMAND_CLASS_MULTI_CHANNEL [0x60] (only in NICE DoubleSmart-Control) COMMAND_CLASS_BASIC [0x20] 11.2 - Multichannel Command Class 11.2.1 - DoubleSmart-Control multichannel command classes for Endpoint 1 Generic Device Class: GENERIC_TYPE_SWITCH_BINARY Specific Device Class: SPECIFIC_TYPE_POWER_SWITCH_BINARY Description: 1st channel • Command classes for Endpoint 1: •...
- Page 14 11.3 - Notification command class The device uses Notification Command Class to report different events to the controller using the Lifeline group (only in Root / Endpoint 1). Table A7 - DoubleSmart-Control - Notification Command Class Notification Type Event Parameter Status 0xFF –...
-
Page 15: Technical Specifications
TECHNICAL SPECIFICATIONS Table A9 - DoubleSmart-Control - Technical Specifications Feature Description Power Supply 100-240 V~ 50/60 Hz or 24-30 V Rated Load Current 6 A per one channel, 9.5 A in total Compatible Load Types resistive or incandescent only Active Element micro-gap relay μ... -
Page 16: Product Disposal
CAUTION! – Local legislation can envisage serious fines in the event of abusive disposal of this product. DECLARATION OF CONFORMITY Hereby, NICE S.p.A., declares that the radio equipment DoubleSmart-Control is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.niceforyou.com/en/professional-area/... - Page 17 Nice SpA Oderzo TV Italia www.niceforyou.com info@niceforyou.com...
