DEVICE CONFIGURATION AND OPERATION
6.1 - Controlling channels with inputs
• Momentary switch (parameter 20 set to 0):
1 x click – change the channel state to the opposite one.
• Toggle switch without memory (parameter 20 set to 1):
1 x switch – change the channel state to the state of the switch (OFF if contacts are opened, ON if contacts are closed).
• Toggle switch with memory (parameter 20 set to 2):
1 x switch – change the channel state to the opposite one.
Note
• By default S1 input controls the 1
and 25.
• By default the outputs are set as NO (normally open), meaning that the contacts are opened when turned off and closed when turned on.
Using parameters 162/163 it can be switched to NC (normally closed), meaning that the contacts are closed when turned off and opened
when turned on.
6.2 - LED indicator lights
The built-in LED indicator light shows the current device status.
6.2.1 - LED indicator lights after powering the device
• Green – device added to a Z-Wave® network (Non-secure, S0, S2 Non-authenticated)
• Magenta – device added to a Z-Wave® network (Security S2 Authenticated)
• Red – device not added to a Z-Wave® network
6.2.2 - LED indicator lights of update
• Blinking cyan – update in progress
• Green – update successful
• Red – update failed
6.2.3 - LED indicator lights of menu
• Blinking green – entering the menu (added as Non-secure, S0, S2 Non-authenticated)
• Blinking magenta – entering the menu (added as Security S2 Authenticated)
• Blinking red – entering the menu (not added to a Z-Wave® network)
• Magenta – testing Z-Wave® network range
• Yellow – resetting to factory settings
6.3 - Menu
Menu allows to perform Z-Wave® network actions. To use the menu:
1. Press and hold the maintenance button to enter the menu.
2. LED indicator light signals the adding status for 3 seconds (see section 6.2.3 for LED indicator lights of menu), then turns off for another 3
seconds.
3. Release the button when device signals the desired position with a specific color:
• Magenta – test the Z-Wave® network range.
• Yellow – reset to factory settings.
4. Quickly click the button to confirm.
6.4 - Activating scenes
The device can activate scenes in the Z-Wave® controller by sending the scene ID and an attribute of a specific action using Central Scene
Command Class.
By default all actions are activated. Change settings of parameters 40 and 41 to disable scene activation for selected actions.
Table A1 - DoubleSmart-Control - Activating scenes
Switch
Switch connected
to S1 terminal
Switch connected
to S2 terminal
* Activating triple clicks disallows the removal using this input.
** Not available for toggle switches.
6
channel and S2 input controls the 2
st
Action
Switch clicked once
Switch clicked twice
Switch clicked thrice*
Switch held**
Switch released**
Switch clicked once
Switch clicked twice
Switch clicked thrice*
Switch held**
Switch released**
channel if it's available. It can be changed using parameters 24
nd
Scene ID Attribute
1 Button pressed 1 time
1 Button pressed 2 times
1 Button pressed 3 times
1 Button held down
1 Button released
2 Button pressed 1 time
2 Button pressed 2 times
2 Button pressed 3 times
2 Button held down
2 Button released
