ADDING TO AND REMOVING FROM Z-WAVE® NETWORK
5.1 - Adding device to Z-Wave® (Inclusion)
It's the Z-Wave® device learning mode. It enables adding the device to an existing Z-Wave® network.
5.1.1 - Adding device to Z-Wave® manually
1. Power on the device.
2. Set the main controller in the add mode (Security/non-Security Mode). See the controller manual.
3. Click the button connected to S1/S2 or the maintenance button quickly, three times.
4. LED indicator light starts blinking in yellow, wait for the adding process to end.
5. If you are adding the device in Security S2 Authenticated Mode, enter the underlined part of the DSK (see the label on the bottom of the
box).
6. Adding is confirmed by the Z-Wave® controller message and the LED indicator light:
• Green – successful (Non-secure, S0, S2 Non-authenticated)
• Magenta – successful (Security S2 Authenticated)
• Red – failed
5.1.2 - Adding device to Z-Wave® using SmartStart
SmartStart enabled products can be added to a Z-Wave® network by scanning the Z-Wave® QR code on the product with a controller
providing SmartStart inclusion. SmartStart product is added automatically within 10 minutes of being switched on in the network range.
To use SmartStart, your controller needs to support Security S2 Mode (see the controller manual).
To add the device to the Z-Wave® network using SmartStart:
1. Enter the full DSK string code into your controller. If possible, scan the QR code placed on the box or the device label. Click the button con-
nected to S1/S2 or the maintenance button quickly, three times.
2. Power on the device.
3. Wait for the adding process to start (up to few minutes), it starts when the LED indicator light starts blinking in yellow.
4. Adding is confirmed by the Z-Wave® controller message and the LED indicator light:
• Green – successful (Non-secure, S0, S2 Non-authenticated)
• Magenta – successful (Security S2 Authenticated)
• Red – failed
Note
In case of problems with adding the device, reset the device and repeat the adding procedure.
5.2 - Removing device from Z-Wave® (Exclusion)
It's the Z-Wave® device learning mode. It enables removing the device from an existing Z-Wave® network. This also resets the device to fac-
tory settings.
Make sure that restoring the factory settings doesn't damage the connected device. We recommend disconnecting the device first.
To remove the device from the Z-Wave® network:
1. Power on the device.
2. Set the main controller in the remove mode (see the controller manual).
3. Click the maintenance button quickly, three times.
4. LED indicator light starts blinking in yellow, wait for the removing process to end.
5. Successful removal is confirmed by the Z-Wave® controller message and red LED indicator light.
