- Page 1 Nice BiDi-Switch Power switch bidirectional interface EN - Instructions and warnings for installation and use...
-
Page 2: Warnings And General Precautions
• The BiDi-Switch control unit has been especially designed for insertion in a junction box or wall box; its housing does not feature any protection against water and only basic protection against contact with solid parts. Never place the BiDi-Switch in inadequately protected environments. - Page 3 3.4 - Power supply The electric power supply of the control unit must be connected by means of terminals L and N (Live, Neutral). The BiDi-Switch control unit can operate with supply voltage of 100 to 240 Volts and frequency of 50 or 60 Hz.
- Page 4 4.1 - Mode I In Mode I the command associated with the transmitter keys is fixed (table A1). In Mode I only one memorisation phase is performed for each transmitter and only one memory location is occupied. During memorisation in Mode I it is not important which key is pressed on the transmitter. Table A1 - Memorisation using Mode I Command Toggle output 1...
- Page 5 4.3 - Mode II In Mode II each key of the transmitter can be associated with one of 6 possible commands (table A5); for example, one automation can be controlled with just one key memorised for the Toggle output 1 command, while the other keys are left free for control of other automations. In Mode II one memorisation phase is performed for each key and each occupies one location in the memory.
-
Page 6: Deleting Transmitters
SETTINGS 5.1 - Auto Off This function allows to automatically turn OFF the connected device when saved time passes from turning ON. By default, the auto OFF func- tion for both outputs is disabled. To set auto OFF time or disable the function, proceed as described below. Table A8 - Setting auto OFF for output 1 Example 01. -
Page 7: Led Signals
5.4 - Factory reset If the control unit needs to be reset to the factory settings (all transmitters and setting will be deleted), proceed as described below. Table A12 - Restoring to factory defaults Example 01. Press and hold the programming pushbutton (fig. 1). 02. -
Page 8: Technical Specifications
The product BiDi-Switch is produced by Nice S.p.a. (TV). Warnings: - All technical specifications stated in this section refer to an ambient temperature of 20 °C (± 5 °C) - Nice S.p.a. reserves the right to apply modifications to the product at any time when deemed necessary, while maintaining the same functionalities and intended use. - Page 9 Nice SpA Oderzo TV Italia www.niceforyou.com info@niceforyou.com...
